Siemens SpeedFax™ HF262 Enclosed Fusible Low Voltage Heavy Duty Safety Switch, 600 VAC/VDC, 60 A, 10 hp, 2 Poles, DPST
Heavy Duty Safety Switches
391641
MFG #: HF262
Siemens
274.74000
/ ea
SIEMENS HF262 2P 600V 60A SFTY SW
- Application GDE URL - Siemens_HNF361_Application_Guide.pdf(Application GDE URL)
- Catalog URL - Siemens_HF324SS_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_HF262.pdf(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Owners Manual URL - SIE_IM_SwitchMaintenance.pdf(Owners Manual URL)
- Spec Sheet 1 URL - Siemens_HF262_Specification_Sheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - 10991_WLR3SHMB09D8KYFU.pdf(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:HF262&language=en(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:HF262&language=en(Spec Sheet URL)
- Spec Sheet URL - SF17-04-011.pdf(Spec Sheet URL)
- Video - https://digitalcontentcenter.compas.siemens-info.com/SIE_VI_Safety_Switch.mp4(Video)
- User Manual URL - man(User Manual URL)
- Features
| Visible blade, double break switching action |
| Highly visible red handle grip designed for hook stick operation |
| Defeatable dual cover interlock, center punch provided for field drilling to allow on padlocking |
| Handle can be padlocked in the OFF position with up to three padlocks with 5/16 in hasps |
| Generous top, bottom and side gutters that meet or exceed NEC wire bending space requirements |
| Tangential knockouts through 600 A for easy conduit lineup |
| Side hinged door that opens past 180 deg for easier wiring |
| Lugs are field convertible to copper body and to a wide variety of compression connectors |
| Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals |
| Embossed aluminum nameplate on heavy duty switches provides highly visible ON/OFF indication |
| Drawn cover for increased rigidity and resistance to abuse |
| Top key hole and bottom mounting holes provide easy 2 or 3-point mounting |
| Without insulation |
