Siemens NGG1B110L Low Voltage Molded Case Circuit Breaker With Lugs, 347/277 VAC, 110 A, 14 to 25 kA Interrupt, 1 Pole
Molded Case Circuit Breakers
648571
MFG #: NGG1B110L
Siemens
726.90000
/ ea
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
- Brochure URL - Siemens-Molded-Case-Circuit-Breakers-GenApp-Catalog-NGG-Product-Guide.pdf(Brochure URL)
- Catalog URL - Siemens_NGB1B015_Catalog.pdf(Catalog URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:NGG1B110L&language=en(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:NGG1B110L&language=en(Spec Sheet URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_NGG-1-Pole-2-Pole-3-Pole.dwg(Computer~Aided [CAD|BIM] Model URL)
- User Manual URL - man(User Manual URL)
- Spec Sheet URL - Siemens-Molded-Case-Circuit-Breakers-NGG-Cut-Sheet.pdf(Spec Sheet URL)
- User Manual URL - SIE_IS_MoldedCaseCircuitBreak_806933.pdf(User Manual URL)
- Features
| GENERAL APPLICATION |
| NGG frame with standard breaking capacity |
