Siemens NGG1B020L Low Voltage Molded Case Circuit Breaker With Lugs, 347/277 VAC, 20 A, 14 to 25 kA Interrupt, 1 Pole
Molded Case Circuit Breakers
501540
MFG #: NGG1B020L
Siemens
202.50000
/ ea
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
- Brochure URL - Siemens-Molded-Case-Circuit-Breakers-GenApp-Catalog-NGG-Product-Guide.pdf(Brochure URL)
- Catalog URL - Siemens_NGB1B015_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_NGG-1-Pole-2-Pole-3-Pole.dwg(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:NGG1B020L&language=en(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:NGG1B020L&language=en(Spec Sheet URL)
- Spec Sheet URL - SF17-07-039.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- User Manual URL - SIE_IS_MoldedCaseCircuitBreak_806933.pdf(User Manual URL)
- Features
| GENERAL APPLICATION |
| NGG frame with standard breaking capacity |
