Siemens
Siemens NGB3B080 Low Voltage Molded Case Circuit Breaker, 600Y/347/480Y/277 VAC, 80 A, 14 to 25 kA Interrupt, 3 Poles
Custom_Product_Images_Illustration
Siemens
Siemens NGB3B080 Low Voltage Molded Case Circuit Breaker, 600Y/347/480Y/277 VAC, 80 A, 14 to 25 kA Interrupt, 3 Poles
SKU403251
MFGR #NGB3B080
Your Cost: $2,072.10/ea
List: Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
Alternate Catalog Number US2:NGB3B080 ARRA Compliant C Buy American Compliant C Catalog Number NGB3B080 Connection Type Load Country of Origin MX Currency USD Dimensions 5.4 in H x 3 in W x 2.8 in D EU RoHS Indicator C Frequency Rating 50/60 Hz Gross Volume Per Pack 192.05 Gross Volume UOM in Gross Weight Per Pack 3.0000 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 4.6500 in Height [Metric] 11.8110 cm Length 7.0000 in Length [Metric] 17.7800 cm Mounting Type Panel Number Of Poles 3 Phase 3 pH Returnable N Standard UL/CSA/IEC/NOM Standards ARRA CompliantBuy American Act CompliantRoHS Compliant Temperature Rating 50 °C Type Type NGB Low Voltage UNSPSC 39121601 UPC 11 78364355349 UPC 12 783643553491 Width 5.9000 in Width [Metric] 14.9860 cm Wire Size 8 to 1/0 AWG, 8 to 2/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 80 A Interrupt Rating 14 to 25 kA Trip Type LI/Thermal Magnetic Voltage Rating 600Y/347/480Y/277 VAC PANELBOARD MOUNT NGB frame with standard breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
Alternate Catalog Number | US2:NGB3B080 |
ARRA Compliant | C |
Buy American Compliant | C |
Catalog Number | NGB3B080 |
Connection Type | Load |
Country of Origin | MX |
Currency | USD |
Dimensions | 5.4 in H x 3 in W x 2.8 in D |
EU RoHS Indicator | C |
Frequency Rating | 50/60 Hz |
Gross Volume Per Pack | 192.05 |
Gross Volume UOM | in |
Gross Weight Per Pack | 3.0000 lb |
Gross Weight per Pack Metric | 1.36 |
Gross Weight UOM Metric | kg |
Harmonization Tariff Schedule Code | 8536200020 |
Height | 4.6500 in |
Height [Metric] | 11.8110 cm |
Length | 7.0000 in |
Length [Metric] | 17.7800 cm |
Mounting Type | Panel |
Number Of Poles | 3 |
Phase | 3 pH |
Returnable | N |
Standard | UL/CSA/IEC/NOM |
Standards | ARRA CompliantBuy American Act CompliantRoHS Compliant |
Temperature Rating | 50 °C |
Type | Type NGB Low Voltage |
UNSPSC | 39121601 |
UPC 11 | 78364355349 |
UPC 12 | 783643553491 |
Width | 5.9000 in |
Width [Metric] | 14.9860 cm |
Wire Size | 8 to 1/0 AWG, 8 to 2/0 AWG |
Stock Status | NONSTOCK |
Brand | Siemens |
Manufacturer | Siemens |
Amperage Rating | 80 A |
Interrupt Rating | 14 to 25 kA |
Trip Type | LI/Thermal Magnetic |
Voltage Rating | 600Y/347/480Y/277 VAC |
PANELBOARD MOUNT |
NGB frame with standard breaking capacity |
