Siemens NGB2B100 Low Voltage Molded Case Circuit Breaker, 600Y/347/480Y/277 VAC, 100 A, 14 to 25 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Siemens NGB2B100 Low Voltage Molded Case Circuit Breaker, 600Y/347/480Y/277 VAC, 100 A, 14 to 25 kA Interrupt, 2 Poles
SKU613569
MFGR #NGB2B100
Your Cost: $1,667.45/ea
List: Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
Alternate Catalog Number US2:NGB2B100 ARRA Compliant C Buy American Compliant C Catalog Number NGB2B100 Connection Type Load Country of Origin MX Currency USD Dimensions 5.4 in H x 2 in W x 2.8 in D EU RoHS Indicator C Frame NGB Frequency Rating 50/60 Hz Gross Weight Per Pack 1.8630 lb Gross Weight per Pack Metric 0.84 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Mounting Type Panel Number Of Poles 2 Phase 1 pH Returnable N Standard UL/CSA/IEC/NOM Standards UL ListedHACR Rated Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 78364355336 UPC 12 783643553361 Wire Size 8 to 1/0/8 to 2/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 100 A Interrupt Rating 14 to 25 kA Trip Type LI/Thermal Magnetic Voltage Rating 600Y/347/480Y/277 VAC PANELBOARD MOUNT NGB frame with standard breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | US2:NGB2B100 |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | NGB2B100 |
| Connection Type | Load |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 5.4 in H x 2 in W x 2.8 in D |
| EU RoHS Indicator | C |
| Frame | NGB |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 1.8630 lb |
| Gross Weight per Pack Metric | 0.84 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Mounting Type | Panel |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | N |
| Standard | UL/CSA/IEC/NOM |
| Standards | UL ListedHACR Rated |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364355336 |
| UPC 12 | 783643553361 |
| Wire Size | 8 to 1/0/8 to 2/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 100 A |
| Interrupt Rating | 14 to 25 kA |
| Trip Type | LI/Thermal Magnetic |
| Voltage Rating | 600Y/347/480Y/277 VAC |
| PANELBOARD MOUNT |
| NGB frame with standard breaking capacity |
