Siemens NFK3T250L VL Series Low Voltage Molded Case Circuit Breaker With Lugs, 600Y/347 VAC, 250 A, 18 kA Interrupt, 3 Poles
Siemens NFK3T250L VL Series Low Voltage Molded Case Circuit Breaker With Lugs, 600Y/347 VAC, 250 A, 18 kA Interrupt, 3 Poles
SKU996651
MFGR #NFK3T250L
Your Cost: $15,815.33/ea
List: Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Alternate Catalog Number 3VL3525-1PE38-0AA0 Application GLOBAL NON-INTERCHANGEABLE ARRA Compliant C Buy American Compliant C Catalog Number NFK3T250L Connection LINE & LOAD STANDARD (CU/AL) LUGS Connection Type Line/Load Lug Country of Origin DE Currency USD Dimensions 7.3 in H x 4.1 in W x 3.4 in D EU RoHS Indicator C Frame FG Frequency Rating 50/60 Hz Gross Weight Per Pack 1.0010 lb Gross Weight per Pack Metric 0.45 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 0 Length 0 Material MOLDED CASE CIRCUIT BREAKER Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable N Series VL Series Standard UL Standards UL Listed Sub Brand VL Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 88762113414 UPC 12 887621134143 Width 0 Wire Size 4 AWG to 350 kcmil Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 250 A Interrupt Rating 18 kA Trip Type LS/I Electronic Voltage Rating 600Y/347 VAC GLOBAL NON-INTERCHANGEABLE LONG DELAY/SHORT DELAY/& INSTANTANEOUS TRIP FUNCTIONS The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breakers are HACR rated Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs Most VL breakers are also available with 100% ratings High reliability most VL components are tested to twice the endurance specified by UL NFG frame with normal breaking capacity Global non-interchangeable
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 3VL3525-1PE38-0AA0 |
| Application | GLOBAL NON-INTERCHANGEABLE |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | NFK3T250L |
| Connection | LINE & LOAD STANDARD (CU/AL) LUGS |
| Connection Type | Line/Load Lug |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 7.3 in H x 4.1 in W x 3.4 in D |
| EU RoHS Indicator | C |
| Frame | FG |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 1.0010 lb |
| Gross Weight per Pack Metric | 0.45 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 0 |
| Length | 0 |
| Material | MOLDED CASE CIRCUIT BREAKER |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | N |
| Series | VL Series |
| Standard | UL |
| Standards | UL Listed |
| Sub Brand | VL |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 88762113414 |
| UPC 12 | 887621134143 |
| Width | 0 |
| Wire Size | 4 AWG to 350 kcmil |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 250 A |
| Interrupt Rating | 18 kA |
| Trip Type | LS/I Electronic |
| Voltage Rating | 600Y/347 VAC |
| GLOBAL NON-INTERCHANGEABLE |
| LONG DELAY/SHORT DELAY/& INSTANTANEOUS TRIP FUNCTIONS |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breakers are HACR rated |
| Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units |
| A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| Most VL breakers are also available with 100% ratings |
| High reliability most VL components are tested to twice the endurance specified by UL |
| NFG frame with normal breaking capacity |
| Global non-interchangeable |
