Siemens NEG3B070L Molded Case Circuit Breaker, 240 VAC, 70 A, 85 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Custom_Product_Images_Illustration

SKU404285

MFGR #NEG3B070L

Your Cost: $6,017.21/ea

List: ~~$8,372.00~~ /ea

SIEMENS NEG3B070L EG 70A 3P 35KA MCCB

: Actuator Type
Handle
ARRA Compliant
C
Buy American Compliant
C
Catalog Number
NEG3B070L
Connection Type
Line/Load Lug
Country of Origin
DO
Currency
USD
Dimensions
7 in L x 4 in W x 5 in H
EU RoHS Indicator
C
Frame
125 A
Frequency Rating
50/60 Hz
Gross Weight Per Pack
3.0000 lb
Gross Weight per Pack Metric
1.36
Gross Weight UOM Metric
kg
Harmonization Tariff Schedule Code
8536200040
Height
5.00 in
Height [Metric]
12.7000 cm
Length
7.00 in
Length [Metric]
17.7800 cm
Number Of Poles
3
Phase
3 pH
Returnable
N
Standard
UL/CSA/IEC/NOM
Standards
ARRA CompliantBuy American Act CompliantRoHS CompliantHACR RatedUL 489
Type
Type NEG Low Voltage
UNSPSC
39121601
UPC 11
78364351989
UPC 12
783643519893
Width
4.00 in
Width [Metric]
10.1600 cm
Wire Size
14 to 1/0 AWG
Stock Status
NONSTOCK
Brand
Siemens
Manufacturer
Siemens
Amperage Rating
70 A
Interrupt Rating
85 kA
Trip Type
Interchangeable/Thermal Magnetic
Voltage Rating
240 VAC
: Catalog
Computer~Aided [CAD|BIM] Model
Seller Home Page
Spec Sheet
Spec Sheet
Spec Sheet
User Manual
User Manual
: GENERAL APPLICATION

1/0 to 14 AWG copper aluminum wire range

Suitable for screw mounting

Global interchangeable

Actuator Type	Handle
ARRA Compliant	C
Buy American Compliant	C
Catalog Number	NEG3B070L
Connection Type	Line/Load Lug
Country of Origin	DO
Currency	USD
Dimensions	7 in L x 4 in W x 5 in H
EU RoHS Indicator	C
Frame	125 A
Frequency Rating	50/60 Hz
Gross Weight Per Pack	3.0000 lb
Gross Weight per Pack Metric	1.36
Gross Weight UOM Metric	kg
Harmonization Tariff Schedule Code	8536200040
Height	5.00 in
Height [Metric]	12.7000 cm
Length	7.00 in
Length [Metric]	17.7800 cm
Number Of Poles	3
Phase	3 pH
Returnable	N
Standard	UL/CSA/IEC/NOM
Standards	ARRA CompliantBuy American Act CompliantRoHS CompliantHACR RatedUL 489
Type	Type NEG Low Voltage
UNSPSC	39121601
UPC 11	78364351989
UPC 12	783643519893
Width	4.00 in
Width [Metric]	10.1600 cm
Wire Size	14 to 1/0 AWG
Stock Status	NONSTOCK
Brand	Siemens
Manufacturer	Siemens
Amperage Rating	70 A
Interrupt Rating	85 kA
Trip Type	Interchangeable/Thermal Magnetic
Voltage Rating	240 VAC
