Siemens NEG2B100L VL Series Low Voltage Molded Case Circuit Breaker With Lugs, 240 VAC, 100 A, 85 kA Interrupt, 2 Poles
Siemens NEG2B100L VL Series Low Voltage Molded Case Circuit Breaker With Lugs, 240 VAC, 100 A, 85 kA Interrupt, 2 Poles
SKU592103
MFGR #NEG2B100L
Your Cost: $4,821.25/ea
List: Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
ARRA Compliant C Buy American Compliant C Catalog Number NEG2B100L Connection Type Line/Load Country of Origin DO Currency USD Dimensions 6 in L x 4 in W x 3 in H EU RoHS Indicator C Frequency Rating 50/60 Hz Gross Weight Per Pack 2.0000 lb Gross Weight per Pack Metric 0.91 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.00 in Height [Metric] 7.6200 cm Length 6.00 in Length [Metric] 15.2400 cm Number Of Poles 2 Phase 1 pH Returnable N Series VL Series Standard UL/CSA/IEC/NOM Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedHACR Rated Temperature Rating 50 °C Type Type NEG Low Voltage UNSPSC 39121601 UPC 11 78364351977 UPC 12 783643519770 Width 4.00 in Width [Metric] 10.1600 cm Wire Size 8 to 1/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 100 A Interrupt Rating 85 kA Trip Type Thermal Magnetic/Interchangeable/LI Voltage Rating 240 VAC GENERAL APPLICATION VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint Communication is possible over PROFIBUS DP or Modbus RTU with electronic trip units A wide variety of protection options ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs High reliability most VL components are tested to twice the endurance specified by UL NEG frame with standard breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | NEG2B100L |
| Connection Type | Line/Load |
| Country of Origin | DO |
| Currency | USD |
| Dimensions | 6 in L x 4 in W x 3 in H |
| EU RoHS Indicator | C |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 2.0000 lb |
| Gross Weight per Pack Metric | 0.91 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.00 in |
| Height [Metric] | 7.6200 cm |
| Length | 6.00 in |
| Length [Metric] | 15.2400 cm |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | N |
| Series | VL Series |
| Standard | UL/CSA/IEC/NOM |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedHACR Rated |
| Temperature Rating | 50 °C |
| Type | Type NEG Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364351977 |
| UPC 12 | 783643519770 |
| Width | 4.00 in |
| Width [Metric] | 10.1600 cm |
| Wire Size | 8 to 1/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 100 A |
| Interrupt Rating | 85 kA |
| Trip Type | Thermal Magnetic/Interchangeable/LI |
| Voltage Rating | 240 VAC |
| GENERAL APPLICATION |
| VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint |
| Communication is possible over PROFIBUS DP or Modbus RTU with electronic trip units |
| A wide variety of protection options ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| High reliability most VL components are tested to twice the endurance specified by UL |
| NEG frame with standard breaking capacity |
