Siemens NEB1B030B Low Voltage Molded Case Circuit Breaker With Lugs, 347 VAC, 30 A, 35 kA Interrupt, 1 Pole
Siemens NEB1B030B Low Voltage Molded Case Circuit Breaker With Lugs, 347 VAC, 30 A, 35 kA Interrupt, 1 Pole
SKU813717
MFGR #NEB1B030B
Your Cost: $2,266.17/ea
List: Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as Switching Duty ratings for 15 to 20 A and HID ratings from 15 to 50 A.
ARRA Compliant C Buy American Compliant C Catalog Number NEB1B030B Connection Type Bolt-On Country of Origin DO Currency USD Dimensions 5-1/2 in H x 1 in W x 3 in D EU RoHS Indicator C Frame NEB Frequency Rating 50/60 Hz Gross Weight Per Pack 1.2500 lb Gross Weight per Pack Metric 0.57 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Mounting Type Panel Number Of Poles 1 Phase 1 pH Returnable N Standard UL/CSA/IEC/NOM Standards UL Listed Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 78364355817 UPC 12 783643558175 Wire Size 8 to 1/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 30 A Interrupt Rating 35 kA Trip Type LI/Thermal Magnetic Voltage Rating 347 VAC PANELBOARD MOUNTING NEB frame with standard breaking capacity Global interchangeable
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | NEB1B030B |
| Connection Type | Bolt-On |
| Country of Origin | DO |
| Currency | USD |
| Dimensions | 5-1/2 in H x 1 in W x 3 in D |
| EU RoHS Indicator | C |
| Frame | NEB |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 1.2500 lb |
| Gross Weight per Pack Metric | 0.57 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Mounting Type | Panel |
| Number Of Poles | 1 |
| Phase | 1 pH |
| Returnable | N |
| Standard | UL/CSA/IEC/NOM |
| Standards | UL Listed |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364355817 |
| UPC 12 | 783643558175 |
| Wire Size | 8 to 1/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 30 A |
| Interrupt Rating | 35 kA |
| Trip Type | LI/Thermal Magnetic |
| Voltage Rating | 347 VAC |
| PANELBOARD MOUNTING |
| NEB frame with standard breaking capacity |
| Global interchangeable |
