Siemens LGG3B070L Low Voltage Molded Case Circuit Breaker, 480 VAC, 70 A, 65 kA Interrupt, 3 Poles
Custom_Product_Images_Illustration
Siemens LGG3B070L Low Voltage Molded Case Circuit Breaker, 480 VAC, 70 A, 65 kA Interrupt, 3 Poles
SKU901691
MFGR #LGG3B070L
Your Cost: $1,493.77/ea
List: Siemens Molded Case Circuit Breaker, Low Voltage, 480 VAC, 70 A, 50/60 Hz, 65 kA Interrupt, LGG Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Cable In/Out/Line/Load Side Lug, 8 to 1/0 AWG Al/Cu Wire, DIN Rail/Threaded Mount, 40 deg C, 5.4 in H x 3 in W x 2.8 in D
Siemens Molded Case Circuit Breaker, Low Voltage, 480 VAC, 70 A, 50/60 Hz, 65 kA Interrupt, LGG Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Cable In/Out/Line/Load Side Lug, 8 to 1/0 AWG Al/Cu Wire, DIN Rail/Threaded Mount, 40 deg C, 5.4 in H x 3 in W x 2.8 in D
Alternate Catalog Number US2:LGG3B070L ARRA Compliant C Buy American Compliant C Catalog Number LGG3B070L Connection Type Cable In/Out/Line/Load Side Lug Country of Origin MX Currency USD Dimensions 5.4 in H x 3 in W x 2.8 in D EU RoHS Indicator C Frame LGG Frequency Rating 50/60 Hz Gross Volume Per Pack 140.30 Gross Volume UOM in Gross Weight Per Pack 6.3500 lb Gross Weight per Pack Metric 2.88 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 6.9500 in Height [Metric] 17.6530 cm Length 4.7500 in Length [Metric] 12.0650 cm Mounting Type DIN Rail/Threaded Number Of Poles 3 Phase 3 pH Returnable N Standard UL/CSA/IEC/NOM Standards UL 489, CSA C22.2 Certified Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 88762127924 UPC 12 887621279240 Width 4.2500 in Width [Metric] 10.7950 cm Wire Size 8 to 1/0 AWG Al/Cu Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 70 A Interrupt Rating 65 kA Trip Type Thermal Magnetic Voltage Rating 480 VAC GENERAL APPLICATION LGG frame with very high breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | US2:LGG3B070L |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | LGG3B070L |
| Connection Type | Cable In/Out/Line/Load Side Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 5.4 in H x 3 in W x 2.8 in D |
| EU RoHS Indicator | C |
| Frame | LGG |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 140.30 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 6.3500 lb |
| Gross Weight per Pack Metric | 2.88 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 6.9500 in |
| Height [Metric] | 17.6530 cm |
| Length | 4.7500 in |
| Length [Metric] | 12.0650 cm |
| Mounting Type | DIN Rail/Threaded |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | N |
| Standard | UL/CSA/IEC/NOM |
| Standards | UL 489, CSA C22.2 Certified |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 88762127924 |
| UPC 12 | 887621279240 |
| Width | 4.2500 in |
| Width [Metric] | 10.7950 cm |
| Wire Size | 8 to 1/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 70 A |
| Interrupt Rating | 65 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 480 VAC |
| GENERAL APPLICATION |
| LGG frame with very high breaking capacity |
