Siemens
Siemens HNX3W100L Speedfax™ VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 1000 A, 35 kA Interrupt, 3 Poles
Siemens
Siemens HNX3W100L Speedfax™ VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 1000 A, 35 kA Interrupt, 3 Poles
SKU806008
MFGR #HNX3W100L
Your Cost: $44,299.73/ea
List: Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Actuator N/A Alternate Catalog Number 3VL7110-2PD38-0AA0 Application GLOBAL NON-INTERCHANGEABLE ARRA Compliant C Auxiliary Contacts N/A Buy American Compliant C Catalog Number HNX3W100L Connection LINE & LOAD STANDARD (CU/AL) LUGS Connection Type Line/Load Lug Country of Origin MX Currency USD Dimensions 16 in H x 9 in W x 6.2 in D Enclosure N/A Environmental Conditions N/A EU RoHS Indicator C Frame NG Frequency Rating 50/60 Hz Gross Weight Per Pack 0.9920 lb Gross Weight per Pack Metric 0.45 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 0 Length 0 Load Rating N/A Material MOLDED CASE CIRCUIT BREAKER Number Of Poles 3 Operating Temperature 40 °C Returnable N Series VL Series Standard UL Standards UL ListedRoHS Compliant Sub Brand VL Temperature Rating 40 °C Trip Range N/A Type Low Voltage UNSPSC 39121601 UPC 11 04089279717 UPC 12 040892797176 Width 0 Wire Size 1/0 AWG to 500 kcmil Al/Cu Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 1000 A Interrupt Rating 35 kA Trip Type Electronic Voltage Rating 600 VAC GLOBAL NON-INTERCHANGEABLE LONG DELAY/INSTANTANEOUS/& GROUND FAULT TRIP FUNCTIONS The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breakers are HACR rated Communication is possible over PROFIBUS DP/MODBUS RTU with electronic trip units A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs Most VL breakers are with 100% ratings High reliability most VL components are tested to twice the endurance specified by UL Global non-interchangeable Without auxiliary release and auxiliary/alarm switch Long delay, instantaneous and ground fault trip functions High IC rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | N/A |
| Alternate Catalog Number | 3VL7110-2PD38-0AA0 |
| Application | GLOBAL NON-INTERCHANGEABLE |
| ARRA Compliant | C |
| Auxiliary Contacts | N/A |
| Buy American Compliant | C |
| Catalog Number | HNX3W100L |
| Connection | LINE & LOAD STANDARD (CU/AL) LUGS |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 16 in H x 9 in W x 6.2 in D |
| Enclosure | N/A |
| Environmental Conditions | N/A |
| EU RoHS Indicator | C |
| Frame | NG |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.9920 lb |
| Gross Weight per Pack Metric | 0.45 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 0 |
| Length | 0 |
| Load Rating | N/A |
| Material | MOLDED CASE CIRCUIT BREAKER |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Returnable | N |
| Series | VL Series |
| Standard | UL |
| Standards | UL ListedRoHS Compliant |
| Sub Brand | VL |
| Temperature Rating | 40 °C |
| Trip Range | N/A |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 04089279717 |
| UPC 12 | 040892797176 |
| Width | 0 |
| Wire Size | 1/0 AWG to 500 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 1000 A |
| Interrupt Rating | 35 kA |
| Trip Type | Electronic |
| Voltage Rating | 600 VAC |
| GLOBAL NON-INTERCHANGEABLE |
| LONG DELAY/INSTANTANEOUS/& GROUND FAULT TRIP FUNCTIONS |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breakers are HACR rated |
| Communication is possible over PROFIBUS DP/MODBUS RTU with electronic trip units |
| A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| Most VL breakers are with 100% ratings |
| High reliability most VL components are tested to twice the endurance specified by UL |
| Global non-interchangeable |
| Without auxiliary release and auxiliary/alarm switch |
| Long delay, instantaneous and ground fault trip functions |
| High IC rating |
