Siemens HNX3V100L Speedfax™ VL Series Molded Case Circuit Breaker, 600 VAC, 1000 A, 65 kA Interrupt, 3 Poles, Electronic Trip
Molded Case Circuit Breakers
806009
MFG #: HNX3V100L
Siemens
34796.31000
/ ea
Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
- Features
| LONG DELAY/SHORT DELAY/INSTANTANEOUS/& GROUND FAULT TRIP FUNCTIONS |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breakers are HACR rated |
| Communication is possible over PROFIBUS DP/MODBUS RTU with electronic trip units |
| A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| Most VL breakers are with 100% ratings |
| High reliability most VL components are tested to twice the endurance specified by UL |
| Global non-interchangeable |
| Without auxiliary release and auxiliary/alarm switch |
| Long, short delay, instantaneous and ground fault trip functions |
| High IC rating |
