Siemens HNF368R Heavy Duty Non-Fusible Safety Switch, 600 VAC, 1200 A, 50/500 hp, 3 Poles, ST
Custom_Product_Images_Illustration
Siemens HNF368R Heavy Duty Non-Fusible Safety Switch, 600 VAC, 1200 A, 50/500 hp, 3 Poles, ST
SKU631265
MFGR #HNF368R
Your Cost: $7,763.16/ea
List: SIEMENS HNF368R 3P 600V 1200A SFTY SW
SIEMENS HNF368R 3P 600V 1200A SFTY SW
Actuator SINGLETHROW Alternate Catalog Number US2:HNF368R Application DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS ARRA Compliant C Buy American Compliant C Catalog Number HNF368R Connection MECHANICALLUGS Country of Origin MX Currency USD Enclosure NEMA3R EU RoHS Indicator C Frequency Rating TRUE Gross Volume Per Pack 37668.15 Gross Volume UOM in Gross Weight Per Pack 270.0000 lb Gross Weight per Pack Metric 122.47 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536509045 Height 12.0000 in Height [Metric] 30.4800 cm Length 73.0000 in Length [Metric] 185.4200 cm Material Steel Mounting Surface Number Of Poles 3 Operating Cycles 2500 Operating Temperature -29 °C Returnable Y Standard UL98 Standards Arra, BuyAmerican Compliant, RoHS Compliant, UL Listed Sub Brand VBII Switch Type SINGLETHROW Type HEAVYDUTYSWITCH UNSPSC 39122205 UPC 11 78364315180 UPC 12 783643151802 Width 43.0000 in Width [Metric] 109.2200 cm Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 1,200 A DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS Quick-make, quick-break operating mechanism that ensures positive operation Visible blade, double-break switching action Arc chutes dissipate heat and prolong switch life Highly visible red handle grip Designed for hook stick operation Defeatable dual cover interlock Center punch provided for field drilling to allow ON padlocking Handle can be padlocked in the OFF position with up to (3) padlocks with 5/16 in hasps Generous top, bottom and side gutters that meet or exceed NEC wire-bending space requirements Informative door labeling which includes replacement parts list Tangential knockouts through 600 A for easy conduit lineup Side-hinged door that opens past 180 degrees for easier wiring Unique enclosure design increases rigidity and prevents cuts and scrapes to conductors and installer's hands Spring reinforced fuse clips that assure reliable contact for cool operation Door latch securely holds door closed and allows cover padlocking Front removable mechanical lugs that are suitable for copper/aluminum 60 or 75 deg C conductors Lugs are field convertible to copper body and to a wide variety of compression connectors Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals Embossed aluminum nameplate on heavy duty switches provides highly visible ON/OFF indication Drawn cover for increased rigidity and resistance to abuse
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | SINGLETHROW |
| Alternate Catalog Number | US2:HNF368R |
| Application | DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HNF368R |
| Connection | MECHANICALLUGS |
| Country of Origin | MX |
| Currency | USD |
| Enclosure | NEMA3R |
| EU RoHS Indicator | C |
| Frequency Rating | TRUE |
| Gross Volume Per Pack | 37668.15 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 270.0000 lb |
| Gross Weight per Pack Metric | 122.47 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536509045 |
| Height | 12.0000 in |
| Height [Metric] | 30.4800 cm |
| Length | 73.0000 in |
| Length [Metric] | 185.4200 cm |
| Material | Steel |
| Mounting | Surface |
| Number Of Poles | 3 |
| Operating Cycles | 2500 |
| Operating Temperature | -29 °C |
| Returnable | Y |
| Standard | UL98 |
| Standards | Arra, BuyAmerican Compliant, RoHS Compliant, UL Listed |
| Sub Brand | VBII |
| Switch Type | SINGLETHROW |
| Type | HEAVYDUTYSWITCH |
| UNSPSC | 39122205 |
| UPC 11 | 78364315180 |
| UPC 12 | 783643151802 |
| Width | 43.0000 in |
| Width [Metric] | 109.2200 cm |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 1,200 A |
| DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS |
| Quick-make, quick-break operating mechanism that ensures positive operation |
| Visible blade, double-break switching action |
| Arc chutes dissipate heat and prolong switch life |
| Highly visible red handle grip |
| Designed for hook stick operation |
| Defeatable dual cover interlock |
| Center punch provided for field drilling to allow ON padlocking |
| Handle can be padlocked in the OFF position with up to (3) padlocks with 5/16 in hasps |
| Generous top, bottom and side gutters that meet or exceed NEC wire-bending space requirements |
| Informative door labeling which includes replacement parts list |
| Tangential knockouts through 600 A for easy conduit lineup |
| Side-hinged door that opens past 180 degrees for easier wiring |
| Unique enclosure design increases rigidity and prevents cuts and scrapes to conductors and installer's hands |
| Spring reinforced fuse clips that assure reliable contact for cool operation |
| Door latch securely holds door closed and allows cover padlocking |
| Front removable mechanical lugs that are suitable for copper/aluminum 60 or 75 deg C conductors |
| Lugs are field convertible to copper body and to a wide variety of compression connectors |
| Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals |
| Embossed aluminum nameplate on heavy duty switches provides highly visible ON/OFF indication |
| Drawn cover for increased rigidity and resistance to abuse |
