Siemens HJG2B300L VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 300 A, 65 kA Interrupt, 2 Poles
Siemens HJG2B300L VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 300 A, 65 kA Interrupt, 2 Poles
SKU580127
MFGR #HJG2B300L
Your Cost: $20,776.37/ea
List: Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Actuator Type 40DEGC Alternate Catalog Number US2:HJG2B300L Application GLOBAL INTERCHANGEABLE ARRA Compliant C Buy American Compliant C Catalog Number HJG2B300L Connection LINE & LOAD STANDARD (CU/AL) LUGS Connection Type Line/Load Lug Country of Origin DE Currency USD Dimensions 11 in L x 5.5 in W x 4.2 in H EU RoHS Indicator C Frame JG Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0100 lb Gross Weight per Pack Metric 0.00 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 0 Length 0 Material MOLDED CASE CIRCUIT BREAKER Number Of Poles 2 Operating Temperature 40 °C Phase 1-Phase Power Rating UL/IEC/CE/CSA/NOM/CCC Returnable N Series VL Series Standard UL/IEC/CE/CSA/NOM/CCC Standards cUL Listed, IEC, CCC, CE, CSA, NOM Certified Sub Brand VL Temperature Rating 40 °C Trip Range LINE & LOAD STANDARD (CU/AL) LUGS Type Low Voltage UNSPSC 39121601 UPC 11 78364358719 UPC 12 783643587199 Width 0 Wire Size 3/0 AWG to 250 kcmil Al/Cu Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 300 A Interrupt Rating 65 kA Trip Type Thermal Magnetic Voltage Rating 600 VAC GLOBAL INTERCHANGEABLE The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs VL breaker are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breaker are HACR rated Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs VL breaker are 100% rated High reliability most VL components are tested to twice the endurance specified by UL HJG frame with high breaking capacity High IC rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | 40DEGC |
| Alternate Catalog Number | US2:HJG2B300L |
| Application | GLOBAL INTERCHANGEABLE |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HJG2B300L |
| Connection | LINE & LOAD STANDARD (CU/AL) LUGS |
| Connection Type | Line/Load Lug |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 11 in L x 5.5 in W x 4.2 in H |
| EU RoHS Indicator | C |
| Frame | JG |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0100 lb |
| Gross Weight per Pack Metric | 0.00 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 0 |
| Length | 0 |
| Material | MOLDED CASE CIRCUIT BREAKER |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1-Phase |
| Power Rating | UL/IEC/CE/CSA/NOM/CCC |
| Returnable | N |
| Series | VL Series |
| Standard | UL/IEC/CE/CSA/NOM/CCC |
| Standards | cUL Listed, IEC, CCC, CE, CSA, NOM Certified |
| Sub Brand | VL |
| Temperature Rating | 40 °C |
| Trip Range | LINE & LOAD STANDARD (CU/AL) LUGS |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364358719 |
| UPC 12 | 783643587199 |
| Width | 0 |
| Wire Size | 3/0 AWG to 250 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 300 A |
| Interrupt Rating | 65 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| GLOBAL INTERCHANGEABLE |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breaker are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breaker are HACR rated |
| Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units |
| A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| VL breaker are 100% rated |
| High reliability most VL components are tested to twice the endurance specified by UL |
| HJG frame with high breaking capacity |
| High IC rating |
