Siemens HEG3B110L VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 110 A, 25 kA Interrupt, 3 Poles
Custom_Product_Images_Illustration
Siemens HEG3B110L VL Series Low Voltage Molded Case Circuit Breaker, 600 VAC, 110 A, 25 kA Interrupt, 3 Poles
SKU549616
MFGR #HEG3B110L
Your Cost: $10,741.95/ea
List: Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
ARRA Compliant C Buy American Compliant C Catalog Number HEG3B110L Connection Type Load Lug Country of Origin DO Currency USD Dimensions 7 in L x 4 in W x 5 in H EU RoHS Indicator C Frame 125 A Frequency Rating 50/60 Hz Gross Weight Per Pack 3.0000 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 5.00 in Height [Metric] 12.7000 cm Length 7.00 in Length [Metric] 17.7800 cm Number Of Poles 3 Phase 3 pH Returnable N Series VL Series Standard UL/CSA/IEC/NOM Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCSA CertifiedIEC CertifiedNOM CertifiedHACR Rated Temperature Rating 40 °C Type Type HEG Low Voltage UNSPSC 39121601 UPC 11 78364352053 UPC 12 783643520530 Width 4.00 in Width [Metric] 10.1600 cm Wire Size 8 to 1/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 110 A Interrupt Rating 25 kA Trip Type Thermal Magnetic Voltage Rating 600 VAC GENERAL APPLICATION The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint Communication is possible over PROFIBUS DP or Modbus RTU with electronic trip units A wide variety of protection options ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs High reliability most VL components are tested to twice the endurance specified by UL With high breaking capacity With high breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HEG3B110L |
| Connection Type | Load Lug |
| Country of Origin | DO |
| Currency | USD |
| Dimensions | 7 in L x 4 in W x 5 in H |
| EU RoHS Indicator | C |
| Frame | 125 A |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.0000 lb |
| Gross Weight per Pack Metric | 1.36 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 5.00 in |
| Height [Metric] | 12.7000 cm |
| Length | 7.00 in |
| Length [Metric] | 17.7800 cm |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | N |
| Series | VL Series |
| Standard | UL/CSA/IEC/NOM |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCSA CertifiedIEC CertifiedNOM CertifiedHACR Rated |
| Temperature Rating | 40 °C |
| Type | Type HEG Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364352053 |
| UPC 12 | 783643520530 |
| Width | 4.00 in |
| Width [Metric] | 10.1600 cm |
| Wire Size | 8 to 1/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 110 A |
| Interrupt Rating | 25 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| GENERAL APPLICATION |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint |
| Communication is possible over PROFIBUS DP or Modbus RTU with electronic trip units |
| A wide variety of protection options ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| High reliability most VL components are tested to twice the endurance specified by UL |
| With high breaking capacity |
