Siemens HDK3B080 VL Series Molded Case Circuit Breaker, 600Y/347 VAC, 80 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Siemens HDK3B080 VL Series Molded Case Circuit Breaker, 600Y/347 VAC, 80 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU817920
MFGR #HDK3B080
Your Cost: $11,031.80/ea
List: Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Siemens VL molded case circuit breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL circuit breakers feature N-Class (35kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL trip units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
Actuator Type MOLDED CASE CIRCUIT BREAKER Alternate Catalog Number 3VL2508-2KN30-0AA0 Application GLOBAL NON-INTERCHANGEABLE ARRA Compliant C Auxiliary Contact Rating 40DEGC ° C Buy American Compliant C Catalog Number HDK3B080 Connection NO-LUGS Connection Type 40DEGC Country of Origin DE Currency USD EU RoHS Indicator C Frame DG Hz Frequency Rating 50/60 Hz Gross Weight Per Pack 4.8500 lb Gross Weight per Pack Metric 2.20 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 0 Length 0 Material MOLDED CASE CIRCUIT BREAKER Number Of Poles 3 Operating Temperature 40 °C Phase NO-LUGS Power Rating UL Returnable N Series VL Series Standard UL Standards UL Listed Sub Brand VL Temperature Rating 40 °C Trip Range 18KA Type Siemens UNSPSC 39121601 UPC 11 88762112657 UPC 12 887621126575 Width 0 Wire Size 40DEGC Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 80 A Interrupt Rating 18 kA Trip Type Thermal Magnetic Voltage Rating 600Y/347 VAC V GLOBAL NON-INTERCHANGEABLE The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs VL breaker are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breaker are HACR rated Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs VL breaker are 100% rated High reliability most VL components are tested to twice the endurance specified by UL Without lugs, auxiliary release, alarm switch and connection accessories
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | MOLDED CASE CIRCUIT BREAKER |
| Alternate Catalog Number | 3VL2508-2KN30-0AA0 |
| Application | GLOBAL NON-INTERCHANGEABLE |
| ARRA Compliant | C |
| Auxiliary Contact Rating | 40DEGC ° C |
| Buy American Compliant | C |
| Catalog Number | HDK3B080 |
| Connection | NO-LUGS |
| Connection Type | 40DEGC |
| Country of Origin | DE |
| Currency | USD |
| EU RoHS Indicator | C |
| Frame | DG Hz |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.8500 lb |
| Gross Weight per Pack Metric | 2.20 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 0 |
| Length | 0 |
| Material | MOLDED CASE CIRCUIT BREAKER |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | NO-LUGS |
| Power Rating | UL |
| Returnable | N |
| Series | VL Series |
| Standard | UL |
| Standards | UL Listed |
| Sub Brand | VL |
| Temperature Rating | 40 °C |
| Trip Range | 18KA |
| Type | Siemens |
| UNSPSC | 39121601 |
| UPC 11 | 88762112657 |
| UPC 12 | 887621126575 |
| Width | 0 |
| Wire Size | 40DEGC |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 80 A |
| Interrupt Rating | 18 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600Y/347 VAC V |
| GLOBAL NON-INTERCHANGEABLE |
| The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory |
| Compact size reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| VL breaker are designed for global use, allowing the user to serve virtually every market using one design and footprint, all VL breaker are HACR rated |
| Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units |
| A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs |
| VL breaker are 100% rated |
| High reliability most VL components are tested to twice the endurance specified by UL |
| Without lugs, auxiliary release, alarm switch and connection accessories |
