Siemens 5SJ4130-7HG42 5SJ4 Type NSJ Miniature Circuit Breaker, 277/480 VAC, 30 A, 10 kA Interrupt, 1 Pole, Thermal Magnetic Trip

Custom_Product_Images_Illustration

SKU835617

MFGR #5SJ4130-7HG42

Your Cost: $57.09/ea

List: ~~$222.00~~ /ea

SIEMENS 5SJ4130-7HG42 MCB UL489 1-P 277VAC 30A C-TRIP TYPE NSJ

: Alternate Catalog Number
5SJ4130-7HG42
Application
BRANCH CIRCUIT PROTECTORS
ARRA Compliant
C
Buy American Compliant
C
Catalog Number
5SJ4130-7HG42
Connection
Identical wire screw connections on line and load side.
Connection Type
Line/Load/Screw
Country of Origin
DE
Currency
USD
Dimensions
121 mm H x 18 mm W x 76 mm D
Enclosure Type
IP20
EU RoHS Indicator
C
Frequency Rating
50 Hz
Gross Volume Per Pack
12.67
Gross Volume UOM
in
Gross Weight Per Pack
0.3900 lb
Gross Weight per Pack Metric
0.18
Gross Weight UOM Metric
kg
Harmonization Tariff Schedule Code
8536200040
Height
0.9000 in
Height [Metric]
2.2860 cm
Length
4.4000 in
Length [Metric]
11.1760 cm
Material
N/A
Mounting Type
DIN Rail
Number Of Poles
1
Returnable
Y
Standard
UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2
Standards
ARRA CompliantBuy American Act CompliantRoHS CompliantCE MarkedCSA 22.2 No. 5-02cULus E24314IEC/EN 60898IEC/EN 60947-2HACR RatedUL 489
Sub Brand
SENTRON
Temperature Rating
-25 to 55 °C
Type
Type NSJ
UNSPSC
39121601
UPC 11
75455495934
UPC 12
754554959344
Width
3.2000 in
Width [Metric]
8.1280 cm
Wire Size
14 to 4 AWG
Stock Status
NONSTOCK
Brand
Siemens
Manufacturer
Siemens
Amperage Rating
30 A
Interrupt Rating
14 kA
Trip Type
Thermal Magnetic
Voltage Rating
240 VAC
: 3D Rendering
Brochure
Seller Home Page
Spec Sheet 1
Spec Sheet
Spec Sheet
Spec Sheet
User Manual
: BRANCH CIRCUIT PROTECTORS
: 1-POLE

Visible indicator for on and off/trip

CFC and silicone-free

Alternate Catalog Number	5SJ4130-7HG42
Application	BRANCH CIRCUIT PROTECTORS
ARRA Compliant	C
Buy American Compliant	C
Catalog Number	5SJ4130-7HG42
Connection	Identical wire screw connections on line and load side.
Connection Type	Line/Load/Screw
Country of Origin	DE
Currency	USD
Dimensions	121 mm H x 18 mm W x 76 mm D
Enclosure Type	IP20
EU RoHS Indicator	C
Frequency Rating	50 Hz
Gross Volume Per Pack	12.67
Gross Volume UOM	in
Gross Weight Per Pack	0.3900 lb
Gross Weight per Pack Metric	0.18
Gross Weight UOM Metric	kg
Harmonization Tariff Schedule Code	8536200040
Height	0.9000 in
Height [Metric]	2.2860 cm
Length	4.4000 in
Length [Metric]	11.1760 cm
Material	N/A
Mounting Type	DIN Rail
Number Of Poles	1
Returnable	Y
Standard	UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2
Standards	ARRA CompliantBuy American Act CompliantRoHS CompliantCE MarkedCSA 22.2 No. 5-02cULus E24314IEC/EN 60898IEC/EN 60947-2HACR RatedUL 489
Sub Brand	SENTRON
Temperature Rating	-25 to 55 °C
Type	Type NSJ
UNSPSC	39121601
UPC 11	75455495934
UPC 12	754554959344
Width	3.2000 in
Width [Metric]	8.1280 cm
Wire Size	14 to 4 AWG
Stock Status	NONSTOCK
Brand	Siemens
Manufacturer	Siemens
Amperage Rating	30 A
Interrupt Rating	14 kA
Trip Type	Thermal Magnetic
Voltage Rating	240 VAC
