Siemens 1LE22213AB116AA3 MOTOR,40,1800,
SKU713836
MFGR #1LE22213AB116AA3
Your Cost: $4,053.81/ea
SIEMENS 1LE22213AB116AA3 MOTOR 40 1800 GP100 230/460 324T NP
SIEMENS 1LE22213AB116AA3 MOTOR 40 1800 GP100 230/460 324T NP
Alternate Catalog Number 1LE2221-3AB11-6AA3 Amperage Rating 46 A Application Type General Purpose Motor ARRA Compliant C Bearing Type Ball Buy American Compliant C Catalog Number 1LE22213AB116AA3 Country of Origin MX Currency USD Dimensions 19.11 in H x 32.07 in W Enclosure Type TEFC/IP54 EU RoHS Indicator C Frequency Rating 60 Hz Gross Volume Per Pack 24360.17 Gross Volume UOM in Gross Weight Per Pack 633.0000 lb Gross Weight per Pack Metric 287.13 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8501528040 Height 22.30 in Height [Metric] 56.6420 cm Insulation Class Class F Length 38.60 in Length [Metric] 98.0440 cm Material Cast Iron Mounting Type Footed Number of Speeds 1 Returnable Y Rotation CW/CCW Series 1LE2 Service Factor 1 Speed 1800 rpm Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCE CertifiedCSA CertifiedcULus RecognizedEE CertifiedWEEE (2012/19/EU) Temperature Rating -20 to 40 °C Type Type GP100 4-Pole Continuous Duty NEMA Low Voltage Standard UNSPSC 26101112 UPC 11 66264392947 UPC 12 662643929478 Width 28.30 in Width [Metric] 71.8820 cm Stock Status NONSTOCK Brand Baldor-Reliance Manufacturer Baldor-Reliance (ABB) Frame 324T Horsepower 40 hp Phase 3 Torque Rating 118 ft-lb Voltage Rating 230/460 VAC NEMA Premium® Efficiency, Squirrel Cage Rotor, Stone Gray Painted, 4:1 Constant Torque, 20:1 Variable Torque Without winding protection Cast iron construction for exceptional structural integrity, equipped with integrally cast feet Condensation drain holes provided Unique frame fin design maximizes cooling Each rotor assembly is dynamically balanced for extended bearing life and includes a high strength carbon steel (C1045) shaft for maximum rotor performance Manufactured with premium electrical grade steel laminations and copper electrical magnet wire to reduce losses and improve efficiencies A unique stator core design lowers flux density while increasing cooling capacity Large conductor cross section reduces resistance and lowers stator losses Proprietary inverter rated NEMA class F non-hygroscopic insulation system with class B temperature rise at 1.0SF, provides an extra margin of thermal life Varnish system application ensures maximum wire penetration to provide protection from moisture, corrosion and electrical surges Insulation system meets or exceeds NEMA MG1-2006, Part 31 making all motors suitable for operation with adjustable frequency drives A bi-directional, non-sparking fan is locked and keyed to the shaft Its design reduces windage losses, improves air flow, reduces noise and provides dependable cooling Polycarbonate fan covers are provided on all frame sizes Lubricated for life, oversized, complete with external V-ring slinger Specially formulated, high temperature, polyurea based grease Oversized cast construction that is larger than industry standards, diagonally split and rotatable in 90 deg increments for quick and easy connections Non-wicking, clearly and permanently marked leads Cast iron construction, polycarbonate fan, corrosion-resistant hardware, epoxy enamel paint resist rust and corrosion
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | 1LE2221-3AB11-6AA3 |
| Amperage Rating | 46 A |
| Application Type | General Purpose Motor |
| ARRA Compliant | C |
| Bearing Type | Ball |
| Buy American Compliant | C |
| Catalog Number | 1LE22213AB116AA3 |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 19.11 in H x 32.07 in W |
| Enclosure Type | TEFC/IP54 |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Volume Per Pack | 24360.17 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 633.0000 lb |
| Gross Weight per Pack Metric | 287.13 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8501528040 |
| Height | 22.30 in |
| Height [Metric] | 56.6420 cm |
| Insulation Class | Class F |
| Length | 38.60 in |
| Length [Metric] | 98.0440 cm |
| Material | Cast Iron |
| Mounting Type | Footed |
| Number of Speeds | 1 |
| Returnable | Y |
| Rotation | CW/CCW |
| Series | 1LE2 |
| Service Factor | 1 |
| Speed | 1800 rpm |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCE CertifiedCSA CertifiedcULus RecognizedEE CertifiedWEEE (2012/19/EU) |
| Temperature Rating | -20 to 40 °C |
| Type | Type GP100 4-Pole Continuous Duty NEMA Low Voltage Standard |
| UNSPSC | 26101112 |
| UPC 11 | 66264392947 |
| UPC 12 | 662643929478 |
| Width | 28.30 in |
| Width [Metric] | 71.8820 cm |
| Stock Status | NONSTOCK |
| Brand | Baldor-Reliance |
| Manufacturer | Baldor-Reliance (ABB) |
| Frame | 324T |
| Horsepower | 40 hp |
| Phase | 3 |
| Torque Rating | 118 ft-lb |
| Voltage Rating | 230/460 VAC |
| NEMA Premium® Efficiency, Squirrel Cage Rotor, Stone Gray Painted, 4:1 Constant Torque, 20:1 Variable Torque |
| Without winding protection |
| Cast iron construction for exceptional structural integrity, equipped with integrally cast feet |
| Condensation drain holes provided |
| Unique frame fin design maximizes cooling |
| Each rotor assembly is dynamically balanced for extended bearing life and includes a high strength carbon steel (C1045) shaft for maximum rotor performance |
| Manufactured with premium electrical grade steel laminations and copper electrical magnet wire to reduce losses and improve efficiencies |
| A unique stator core design lowers flux density while increasing cooling capacity |
| Large conductor cross section reduces resistance and lowers stator losses |
| Proprietary inverter rated NEMA class F non-hygroscopic insulation system with class B temperature rise at 1.0SF, provides an extra margin of thermal life |
| Varnish system application ensures maximum wire penetration to provide protection from moisture, corrosion and electrical surges |
| Insulation system meets or exceeds NEMA MG1-2006, Part 31 making all motors suitable for operation with adjustable frequency drives |
| A bi-directional, non-sparking fan is locked and keyed to the shaft |
| Its design reduces windage losses, improves air flow, reduces noise and provides dependable cooling |
| Polycarbonate fan covers are provided on all frame sizes |
| Lubricated for life, oversized, complete with external V-ring slinger |
| Specially formulated, high temperature, polyurea based grease |
| Oversized cast construction that is larger than industry standards, diagonally split and rotatable in 90 deg increments for quick and easy connections |
| Non-wicking, clearly and permanently marked leads |
| Cast iron construction, polycarbonate fan, corrosion-resistant hardware, epoxy enamel paint resist rust and corrosion |
