Siemens 1LE22212BA214GA3 MOTOR,20,3600,
SKU776020
MFGR #1LE22212BA214GA3
Your Cost: $2,457.37/ea
SIEMENS 1LE22212BA214GA3 MOTOR 20 3600 GP100 230/460 256TC NP
SIEMENS 1LE22212BA214GA3 MOTOR 20 3600 GP100 230/460 256TC NP
Alternate Catalog Number 1LE2221-2BA21-4GA3 Amperage Rating 22.5 A Application Type Compressor Motors, General Purpose AC Motors ARRA Compliant C Bearing Type Ball Buy American Compliant C Catalog Number 1LE22212BA214GA3 Constant Torque Speed Range 4:1 Country of Origin MX Currency USD Dimensions 26.16 in W x 12.75 in H Enclosure Type TEFC/IP54/IP55 EU RoHS Indicator C Frequency Rating 60 Hz Gross Weight Per Pack 293.0000 lb Gross Weight per Pack Metric 132.90 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8501524000 Insulation Class Class F Material Cast Iron Mounting Type C-Face Footless/Floor Returnable Y Rotation Bi-Directional Series 1LE2 Service Factor 1 Shaft Size 1-5/8 in Dia x 4 in L Speed 3600 rpm Standards CE CertifiedCSA CertifiedcULus ListedEE CertifiedNEMA Premium® Standard Temperature Rating -20 to 40 °C Type 2-Pole Continuous Duty Low Voltage Standard Type GP100 UNSPSC 26101112 UPC 11 66264333747 UPC 12 662643337471 Variable Torque Speed Range 20:1 Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Frame 256TC Horsepower 20 hp Phase 3 pH Torque Rating 30 ft-lb Voltage Rating 208 to 230/460 VAC Squirrel Cage Motors Cast iron construction for exceptional structural integrity, equipped with integrally cast feet Condensation drain holes are provided Unique frame fin design maximizes cooling Each rotor assembly is dynamically balanced for extended bearing life and includes a high strength carbon steel (C1045) shaft for maximum rotor performance Manufactured with premium electrical grade steel laminations and copper electrical magnet wire to reduce losses and improved efficiencies A unique stator core design lowers flux density while increasing cooling capacity Large conductor cross section reduces resistance and lowers stator losses Proprietary inverter rated NEMA class F, non-hygroscopic insulation system with class B temperature rise at 1.0 SF provides an extra margin of thermal life Varnish system application ensures maximum wire penetration to provide protection from moisture, corrosion and electrical surges Insulation system meets or exceeds NEMA mg1 2006, part 31, making all motors suitable for operation with adjustable frequency drives A bi-directional, non-sparking fan is locked and keyed to the shaft Its design reduces windage losses, improves airflow, reduces noise and provides dependable cooling Polycarbonate fan covers are provided on all frame sizes Lubricated for life (FS 140 to 400), provisions for lubrication (FS 440), oversized, complete with external bearing protection Specially formulated, high temperature, polyurea based grease Oversized cast iron construction that is larger than industry standards, diagonally split and rotatable in 90 deg increments for quick and easy connections Non-wicking, clearly and permanently marked leads Cast iron construction, polycarbonate fan, corrosion resistant hardware, epoxy enamel paint resist rust and corrosion Without winding protection RAL7030 standard stone gray paint finish
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | 1LE2221-2BA21-4GA3 |
| Amperage Rating | 22.5 A |
| Application Type | Compressor Motors, General Purpose AC Motors |
| ARRA Compliant | C |
| Bearing Type | Ball |
| Buy American Compliant | C |
| Catalog Number | 1LE22212BA214GA3 |
| Constant Torque Speed Range | 4:1 |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 26.16 in W x 12.75 in H |
| Enclosure Type | TEFC/IP54/IP55 |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Weight Per Pack | 293.0000 lb |
| Gross Weight per Pack Metric | 132.90 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8501524000 |
| Insulation Class | Class F |
| Material | Cast Iron |
| Mounting Type | C-Face Footless/Floor |
| Returnable | Y |
| Rotation | Bi-Directional |
| Series | 1LE2 |
| Service Factor | 1 |
| Shaft Size | 1-5/8 in Dia x 4 in L |
| Speed | 3600 rpm |
| Standards | CE CertifiedCSA CertifiedcULus ListedEE CertifiedNEMA Premium® Standard |
| Temperature Rating | -20 to 40 °C |
| Type | 2-Pole Continuous Duty Low Voltage Standard Type GP100 |
| UNSPSC | 26101112 |
| UPC 11 | 66264333747 |
| UPC 12 | 662643337471 |
| Variable Torque Speed Range | 20:1 |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Frame | 256TC |
| Horsepower | 20 hp |
| Phase | 3 pH |
| Torque Rating | 30 ft-lb |
| Voltage Rating | 208 to 230/460 VAC |
| Squirrel Cage Motors |
| Cast iron construction for exceptional structural integrity, equipped with integrally cast feet |
| Condensation drain holes are provided |
| Unique frame fin design maximizes cooling |
| Each rotor assembly is dynamically balanced for extended bearing life and includes a high strength carbon steel (C1045) shaft for maximum rotor performance |
| Manufactured with premium electrical grade steel laminations and copper electrical magnet wire to reduce losses and improved efficiencies |
| A unique stator core design lowers flux density while increasing cooling capacity |
| Large conductor cross section reduces resistance and lowers stator losses |
| Proprietary inverter rated NEMA class F, non-hygroscopic insulation system with class B temperature rise at 1.0 SF provides an extra margin of thermal life |
| Varnish system application ensures maximum wire penetration to provide protection from moisture, corrosion and electrical surges |
| Insulation system meets or exceeds NEMA mg1 2006, part 31, making all motors suitable for operation with adjustable frequency drives |
| A bi-directional, non-sparking fan is locked and keyed to the shaft |
| Its design reduces windage losses, improves airflow, reduces noise and provides dependable cooling |
| Polycarbonate fan covers are provided on all frame sizes |
| Lubricated for life (FS 140 to 400), provisions for lubrication (FS 440), oversized, complete with external bearing protection |
| Specially formulated, high temperature, polyurea based grease |
| Oversized cast iron construction that is larger than industry standards, diagonally split and rotatable in 90 deg increments for quick and easy connections |
| Non-wicking, clearly and permanently marked leads |
| Cast iron construction, polycarbonate fan, corrosion resistant hardware, epoxy enamel paint resist rust and corrosion |
| Without winding protection |
| RAL7030 standard stone gray paint finish |
