Sentron™ ED63B110L Molded Case Circuit Breaker, 600 VAC/250 VDC, 110 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Sentron™ ED63B110L Molded Case Circuit Breaker, 600 VAC/250 VDC, 110 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU514853
MFGR #ED63B110L
Your Cost: $5,734.04/ea
List: Siemens ED63B110L 3P 110A 600V CB
Siemens ED63B110L 3P 110A 600V CB
Actuator Varying Alternate Catalog Number US2:ED63B110L Application Standard 40C Breaker ARRA Compliant C Auxiliary Contacts N/A Buy American Compliant C Catalog Number ED63B110L Connection Line/Load lugs installed Connection Type Line/Load Lug Country of Origin MX Currency USD Dimensions 4 in L x 7 in W x 6 in H Enclosure Varying Environmental Conditions N/A EU RoHS Indicator C Frame ED Frequency Rating 50/60 Hz Gross Volume Per Pack 152.57 Gross Volume UOM in Gross Weight Per Pack 3.1000 lb Gross Weight per Pack Metric 1.41 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 4.0000 in Height [Metric] 10.1600 cm Length 6.0000 in Length [Metric] 15.2400 cm Load Rating N/A Material N/A Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable N Standard HACR Standards ARRA CompliantBuy American Act CompliantRoHS CompliantHACR RatedUL 489 Sub Brand SENTRON Temperature Rating 40 °C Trip Range N/A Type Type ED6 Low Voltage UNSPSC 39121601 UPC 11 78364324464 UPC 12 783643244641 Width 7.0000 in Width [Metric] 17.7800 cm Wire Size 1 to 2/0 AWG, 3 to 3/0 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 110 A Interrupt Rating 18 kA Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC VAC//VDC Standard 40C Breaker N/A All ED frame circuit breakers may be reverse connected (3) 3 to 3/0 AWG copper, 1 to 2/0 AWG aluminum wire range Varying actuator Varying enclosure Blue label
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Varying |
| Alternate Catalog Number | US2:ED63B110L |
| Application | Standard 40C Breaker |
| ARRA Compliant | C |
| Auxiliary Contacts | N/A |
| Buy American Compliant | C |
| Catalog Number | ED63B110L |
| Connection | Line/Load lugs installed |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 4 in L x 7 in W x 6 in H |
| Enclosure | Varying |
| Environmental Conditions | N/A |
| EU RoHS Indicator | C |
| Frame | ED |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 152.57 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 3.1000 lb |
| Gross Weight per Pack Metric | 1.41 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 4.0000 in |
| Height [Metric] | 10.1600 cm |
| Length | 6.0000 in |
| Length [Metric] | 15.2400 cm |
| Load Rating | N/A |
| Material | N/A |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | N |
| Standard | HACR |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantHACR RatedUL 489 |
| Sub Brand | SENTRON |
| Temperature Rating | 40 °C |
| Trip Range | N/A |
| Type | Type ED6 Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364324464 |
| UPC 12 | 783643244641 |
| Width | 7.0000 in |
| Width [Metric] | 17.7800 cm |
| Wire Size | 1 to 2/0 AWG, 3 to 3/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 110 A |
| Interrupt Rating | 18 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC VAC//VDC |
| Standard 40C Breaker |
| N/A |
| All ED frame circuit breakers may be reverse connected |
| (3) 3 to 3/0 AWG copper, 1 to 2/0 AWG aluminum wire range |
| Varying actuator |
| Varying enclosure |
| Blue label |
