Siemens
Sentron™ ED42B035L Type ED4 Molded Case Circuit Breaker With Load Lugs, 480 VAC/250 VDC, 35 A, 18 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Siemens
Sentron™ ED42B035L Type ED4 Molded Case Circuit Breaker With Load Lugs, 480 VAC/250 VDC, 35 A, 18 kA Interrupt, 2 Poles
SKU601013
MFGR #ED42B035L
Your Cost: $1,606.36/ea
List: Sentron™ Molded Case Circuit Breaker, Type ED4, 480 VAC/250 VDC, 35 A, 50/60 Hz, 18 kA Interrupt, ED Frame, Thermal Magnetic Trip, 2 Poles, 1-Phase, Line/Load Lug, 40 deg C, 3 in L x 7 in W x 6 in H
Sentron™ Molded Case Circuit Breaker, Type ED4, 480 VAC/250 VDC, 35 A, 50/60 Hz, 18 kA Interrupt, ED Frame, Thermal Magnetic Trip, 2 Poles, 1-Phase, Line/Load Lug, 40 deg C, 3 in L x 7 in W x 6 in H
Actuator Varying Alternate Catalog Number US2:ED42B035L Application Standard 40C Breaker ARRA Compliant C Auxiliary Contacts N/A Buy American Compliant C Catalog Number ED42B035L Connection Line/Load lugs installed Connection Type Line/Load Lug Country of Origin MX Currency USD Dimensions 3 in L x 7 in W x 6 in H Enclosure Varying Environmental Conditions N/A EU RoHS Indicator C Frame ED Frequency Rating 50/60 Hz Gross Volume Per Pack 120.67 Gross Volume UOM in Gross Weight Per Pack 2.7000 lb Gross Weight per Pack Metric 1.23 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 3.0000 in Height [Metric] 7.6200 cm Length 6.0000 in Length [Metric] 15.2400 cm Load Rating N/A Material N/A Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable N Standard HACR Standards ARRA CompliantBuy American Act CompliantRoHS CompliantHACR Rated Sub Brand SENTRON Temperature Rating 40 °C Trip Range N/A Type Type ED4 Low Voltage UNSPSC 39121601 UPC 11 78364308379 UPC 12 783643083790 Width 7.0000 in Width [Metric] 17.7800 cm Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 35 A Interrupt Rating 18 kA Trip Type Thermal Magnetic Voltage Rating 480 VAC/250 VDC VAC//VDC Standard 40C Breaker N/A Varying actuator
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Varying |
| Alternate Catalog Number | US2:ED42B035L |
| Application | Standard 40C Breaker |
| ARRA Compliant | C |
| Auxiliary Contacts | N/A |
| Buy American Compliant | C |
| Catalog Number | ED42B035L |
| Connection | Line/Load lugs installed |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 3 in L x 7 in W x 6 in H |
| Enclosure | Varying |
| Environmental Conditions | N/A |
| EU RoHS Indicator | C |
| Frame | ED |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 120.67 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 2.7000 lb |
| Gross Weight per Pack Metric | 1.23 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.0000 in |
| Height [Metric] | 7.6200 cm |
| Length | 6.0000 in |
| Length [Metric] | 15.2400 cm |
| Load Rating | N/A |
| Material | N/A |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | N |
| Standard | HACR |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantHACR Rated |
| Sub Brand | SENTRON |
| Temperature Rating | 40 °C |
| Trip Range | N/A |
| Type | Type ED4 Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364308379 |
| UPC 12 | 783643083790 |
| Width | 7.0000 in |
| Width [Metric] | 17.7800 cm |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 35 A |
| Interrupt Rating | 18 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 480 VAC/250 VDC VAC//VDC |
| Standard 40C Breaker |
| N/A |
| Varying actuator |
