Siemens
Sentron™ 5SJ4306-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 6 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Siemens
Sentron™ 5SJ4306-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 6 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU1035046
MFGR #5SJ4306-7HG42
Your Cost: $197.49/ea
List: Sentron™ Miniature Circuit Breaker, 480 VAC/125 VDC, 6 A, 50 Hz, 14 kA Interrupt, NSJ Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Handle Actuator, Screw, 14 to 4 AWG Wire, IP20, DIN Rail Mount, -25 to 55 deg C, 121 mm H x 54 mm W x 70 mm D
Sentron™ Miniature Circuit Breaker, 480 VAC/125 VDC, 6 A, 50 Hz, 14 kA Interrupt, NSJ Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Handle Actuator, Screw, 14 to 4 AWG Wire, IP20, DIN Rail Mount, -25 to 55 deg C, 121 mm H x 54 mm W x 70 mm D
Actuator Type Handle Alternate Catalog Number 5SJ4306-7HG42 Application Miniature Circuit Breakers IEC ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4306-7HG42 Connection Type Screw Country of Origin DE Currency USD Dimensions 121 mm H x 54 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frame NSJ Frequency Rating 50 Hz Gross Volume Per Pack 36.06 Gross Volume UOM in Gross Weight Per Pack 1.0980 lb Gross Weight per Pack Metric 0.50 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.3000 in Height [Metric] 8.3820 cm Length 4.2000 in Length [Metric] 10.6680 cm Mounting Type DIN Rail Number Of Poles 3 Phase 3 Returnable Y Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedEN 60898EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand Controls Temperature Rating -25 to 55 °C Type UL489 Branch Circuit Protection UNSPSC 39121601 UPC 11 75455496024 UPC 12 754554960241 Width 1.7000 in Width [Metric] 4.3180 cm Wire Size 14 to 4 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 6 A Interrupt Rating 14 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC Miniature Circuit Breakers IEC UL489 Branch Circuit Protection 40 deg C calibration base (industrial applications) 30 deg C calibration base Can be used for field wiring applications 14 to 4 AWG copper only Suitable for reverse feed applications C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating 0.75 to 35 mm2 solid and stranded conductors Visible indicator for on and off/trip Touch protection to EN50274 Identical wire screw connections on line and load sides Smaller size than traditional MCCBs 35 mm DIN standard mounting rail Short circuit rating: 14 kA 277/480 VAC/125 VDC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4306-7HG42 |
| Application | Miniature Circuit Breakers IEC |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4306-7HG42 |
| Connection Type | Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 121 mm H x 54 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frame | NSJ |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 36.06 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 1.0980 lb |
| Gross Weight per Pack Metric | 0.50 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.3000 in |
| Height [Metric] | 8.3820 cm |
| Length | 4.2000 in |
| Length [Metric] | 10.6680 cm |
| Mounting Type | DIN Rail |
| Number Of Poles | 3 |
| Phase | 3 |
| Returnable | Y |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedEN 60898EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | Controls |
| Temperature Rating | -25 to 55 °C |
| Type | UL489 Branch Circuit Protection |
| UNSPSC | 39121601 |
| UPC 11 | 75455496024 |
| UPC 12 | 754554960241 |
| Width | 1.7000 in |
| Width [Metric] | 4.3180 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 6 A |
| Interrupt Rating | 14 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| Miniature Circuit Breakers IEC |
| UL489 Branch Circuit Protection |
| 40 deg C calibration base (industrial applications) |
| 30 deg C calibration base |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Suitable for reverse feed applications |
| C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating |
| 0.75 to 35 mm2 solid and stranded conductors |
| Visible indicator for on and off/trip |
| Touch protection to EN50274 |
| Identical wire screw connections on line and load sides |
| Smaller size than traditional MCCBs |
| 35 mm DIN standard mounting rail |
| Short circuit rating: 14 kA |
| 277/480 VAC/125 VDC |
