Siemens
Sentron™ 5SJ4232-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 32 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Siemens
Sentron™ 5SJ4232-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 32 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
SKU751079
MFGR #5SJ4232-7HG42
Your Cost: $132.69/ea
List: SIEMENS 5SJ4232-7HG42 MCB UL489 2-P 480Y/277VAC 32A C TYPE NSJ
SIEMENS 5SJ4232-7HG42 MCB UL489 2-P 480Y/277VAC 32A C TYPE NSJ
Actuator Type Handle Alternate Catalog Number 5SJ4232-7HG42 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4232-7HG42 Connection Identical wire screw connections on line and load side. Connection Type Line/Load/Screw Country of Origin DE Currency USD Dimensions 121 mm H x 36 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 25.66 Gross Volume UOM in Gross Weight Per Pack 0.7580 lb Gross Weight per Pack Metric 0.34 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.3100 in Height [Metric] 8.4074 cm Length 4.9210 in Length [Metric] 12.4993 cm Mounting Type DIN Rail Number Of Poles 2 Phase 1 Returnable Y Standard UL 489 Rated Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedEN 60898EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand SENTRON Temperature Rating -25 to 55 °C Type Type NSJ UNSPSC 39121601 UPC 11 75455495992 UPC 12 754554959924 Width 1.5750 in Width [Metric] 4.0005 cm Wire Size 14 to 4 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 32 A Interrupt Rating 10 kA Trip Type Thermal Magnetic Voltage Rating 277/480Y VAC V BRANCH CIRCUIT PROTECTORS 2 poles Can be used for field wiring applications 14 to 4 AWG copper only Visible indicator for on and off/trip
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4232-7HG42 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4232-7HG42 |
| Connection | Identical wire screw connections on line and load side. |
| Connection Type | Line/Load/Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 121 mm H x 36 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 25.66 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 0.7580 lb |
| Gross Weight per Pack Metric | 0.34 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.3100 in |
| Height [Metric] | 8.4074 cm |
| Length | 4.9210 in |
| Length [Metric] | 12.4993 cm |
| Mounting Type | DIN Rail |
| Number Of Poles | 2 |
| Phase | 1 |
| Returnable | Y |
| Standard | UL 489 Rated |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedEN 60898EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | SENTRON |
| Temperature Rating | -25 to 55 °C |
| Type | Type NSJ |
| UNSPSC | 39121601 |
| UPC 11 | 75455495992 |
| UPC 12 | 754554959924 |
| Width | 1.5750 in |
| Width [Metric] | 4.0005 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 32 A |
| Interrupt Rating | 10 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 277/480Y VAC V |
| BRANCH CIRCUIT PROTECTORS |
| 2 poles |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Visible indicator for on and off/trip |
