Sentron™ 5SJ4145-7HG40 5SJ Miniature Circuit Breaker, 240 VAC, 6 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip

Custom_Product_Images_Illustration

SKU919894

MFGR #5SJ4145-7HG40

Your Cost: $88.30/ea

List: ~~$278.00~~ /ea

SIEMENS 5SJ4145-7HG40 MCB UL489 1-P 45A C-TRIP SAME PHASE ONLY

: Actuator Type
Handle
Alternate Catalog Number
5SJ4145-7HG40
Application
BRANCH CIRCUIT PROTECTORS
ARRA Compliant
C
Buy American Compliant
C
Catalog Number
5SJ4145-7HG40
Connection
Identical wire screw connections on line and load side.
Connection Type
Screw
Country of Origin
DE
Currency
USD
Dimensions
90 mm H x 18 mm W x 70 mm D
Enclosure Type
IP20/IP40
EU RoHS Indicator
C
Frame
HSJ
Frequency Rating
50 Hz
Gross Volume Per Pack
10.22
Gross Volume UOM
in
Gross Weight Per Pack
0.3800 lb
Gross Weight per Pack Metric
0.17
Gross Weight UOM Metric
kg
Harmonization Tariff Schedule Code
8536200040
Height
3.2500 in
Height [Metric]
8.2550 cm
Length
3.7000 in
Length [Metric]
9.3980 cm
Material
N/A
Mounting Type
DIN Rail
Number Of Poles
1
Returnable
Y
Series
5SJ
Standard
UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2
Standards
CSA C22.2 No. 5-02UL 489UL 489AIEC/EN 60 898IEC/EN 60 947-2HACR Rated
Sub Brand
SENTRON
Temperature Rating
-25 to 55 °C
Type
HSJ
UNSPSC
39121601
UPC 11
75455493270
UPC 12
754554932705
Width
0.8500 in
Width [Metric]
2.1590 cm
Wire Size
14 to 4 AWG
Stock Status
NONSTOCK
Brand
Siemens
Manufacturer
Siemens
Amperage Rating
6 A
Interrupt Rating
14 kA
Trip Type
Thermal Magnetic
Voltage Rating
240 VAC
: 3D Rendering
Catalog
Seller Home Page
Spec Sheet
Spec Sheet
Spec Sheet
Spec Sheet
User Manual
: BRANCH CIRCUIT PROTECTORS
: 1-POLE

Actuator Type	Handle
Alternate Catalog Number	5SJ4145-7HG40
Application	BRANCH CIRCUIT PROTECTORS
ARRA Compliant	C
Buy American Compliant	C
Catalog Number	5SJ4145-7HG40
Connection	Identical wire screw connections on line and load side.
Connection Type	Screw
Country of Origin	DE
Currency	USD
Dimensions	90 mm H x 18 mm W x 70 mm D
Enclosure Type	IP20/IP40
EU RoHS Indicator	C
Frame	HSJ
Frequency Rating	50 Hz
Gross Volume Per Pack	10.22
Gross Volume UOM	in
Gross Weight Per Pack	0.3800 lb
Gross Weight per Pack Metric	0.17
Gross Weight UOM Metric	kg
Harmonization Tariff Schedule Code	8536200040
Height	3.2500 in
Height [Metric]	8.2550 cm
Length	3.7000 in
Length [Metric]	9.3980 cm
Material	N/A
Mounting Type	DIN Rail
Number Of Poles	1
Returnable	Y
Series	5SJ
Standard	UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2
Standards	CSA C22.2 No. 5-02UL 489UL 489AIEC/EN 60 898IEC/EN 60 947-2HACR Rated
Sub Brand	SENTRON
Temperature Rating	-25 to 55 °C
Type	HSJ
UNSPSC	39121601
UPC 11	75455493270
UPC 12	754554932705
Width	0.8500 in
Width [Metric]	2.1590 cm
Wire Size	14 to 4 AWG
Stock Status	NONSTOCK
Brand	Siemens
Manufacturer	Siemens
Amperage Rating	6 A
Interrupt Rating	14 kA
Trip Type	Thermal Magnetic
Voltage Rating	240 VAC
