Sentron™ 5SJ4110-7HG41 Miniature Circuit Breaker, 240 VAC/125 VDC, 10 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Sentron™ 5SJ4110-7HG41 Miniature Circuit Breaker, 240 VAC/125 VDC, 10 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
SKU357387
MFGR #5SJ4110-7HG41
Your Cost: $57.09/ea
List: SIEMENS 5SJ4110-7HG41 CIRCUIT BREAKER
SIEMENS 5SJ4110-7HG41 CIRCUIT BREAKER
Actuator Type Handle Alternate Catalog Number 5SJ4110-7HG41 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4110-7HG41 Connection Identical wire screw connections on line and load side. Connection Type Line/Load/Screw Country of Origin DE Currency USD Dimensions 110 mm H x 18 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 13.31 Gross Volume UOM in Gross Weight Per Pack 0.1700 lb Gross Weight per Pack Metric 0.08 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.2500 in Height [Metric] 8.2550 cm Length 4.5500 in Length [Metric] 11.5570 cm Material N/A Mounting Type DIN Rail Number Of Poles 1 Phase 1 Returnable Y Standard UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand SENTRON Temperature Rating -25 to 55 °C Type Type HSJ UNSPSC 39121601 UPC 11 75455493877 UPC 12 754554938776 Width 0.9000 in Width [Metric] 2.2860 cm Wire Size 14 to 4 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 10 A Interrupt Rating 14 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC BRANCH CIRCUIT PROTECTORS 1-POLE 40 deg C calibration base (industrial applications) Can be used for field wiring applications 14 to 4 AWG copper only Visible indicator for on and off/trip
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4110-7HG41 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4110-7HG41 |
| Connection | Identical wire screw connections on line and load side. |
| Connection Type | Line/Load/Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 110 mm H x 18 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 13.31 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 0.1700 lb |
| Gross Weight per Pack Metric | 0.08 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.2500 in |
| Height [Metric] | 8.2550 cm |
| Length | 4.5500 in |
| Length [Metric] | 11.5570 cm |
| Material | N/A |
| Mounting Type | DIN Rail |
| Number Of Poles | 1 |
| Phase | 1 |
| Returnable | Y |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | SENTRON |
| Temperature Rating | -25 to 55 °C |
| Type | Type HSJ |
| UNSPSC | 39121601 |
| UPC 11 | 75455493877 |
| UPC 12 | 754554938776 |
| Width | 0.9000 in |
| Width [Metric] | 2.2860 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 10 A |
| Interrupt Rating | 14 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| BRANCH CIRCUIT PROTECTORS |
| 1-POLE |
| 40 deg C calibration base (industrial applications) |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Visible indicator for on and off/trip |
