Sentron™ 5SJ4103-8HG40 Miniature Circuit Breaker, 240 VAC/60 VDC, 3 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Sentron™ 5SJ4103-8HG40 Miniature Circuit Breaker, 240 VAC/60 VDC, 3 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
SKU515763
MFGR #5SJ4103-8HG40
Your Cost: $51.94/ea
List: SIEMENS 5SJ4103-8HG40 MCB UL489 1-P 3A D-TRIP SAME PHASE ONLY
SIEMENS 5SJ4103-8HG40 MCB UL489 1-P 3A D-TRIP SAME PHASE ONLY
Actuator Type Handle Alternate Catalog Number 5SJ4103-8HG40 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4103-8HG40 Connection Identical wire screw connections on line and load side. Connection Type Line/Load/Screw Country of Origin DE Currency USD Dimensions 90 mm H x 18 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 44.27 Gross Volume UOM in Gross Weight Per Pack 0.3600 lb Gross Weight per Pack Metric 0.16 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 3.2500 in Height [Metric] 8.2550 cm Length 3.8000 in Length [Metric] 9.6520 cm Material N/A Mounting Type DIN Rail Number Of Poles 1 Phase 1 Returnable Y Standard UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand SENTRON Temperature Rating -25 to 55 °C Type Type HSJ UNSPSC 39121601 UPC 11 75455493233 UPC 12 754554932330 Width 1.2000 in Width [Metric] 3.0480 cm Wire Size 14 to 4 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 3 A Interrupt Rating 14 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC BRANCH CIRCUIT PROTECTORS 1-POLE 40 deg C calibration base (industrial applications) 30 deg C calibration base Can be used for field wiring applications 14 to 4 AWG copper only Suitable for reverse feed applications D-trip is designed for high inrush loads. Magnetic trip point is 10 to 20 times the MCB rating 0.75 to 35 mm2 solid and stranded conductors Visible indicator for on and off/trip Touch protection to EN50274 Identical wire screw connections on line and load sides Smaller size than traditional MCCBs 35 mm DIN standard mounting rail Short circuit rating: 14 kA
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4103-8HG40 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4103-8HG40 |
| Connection | Identical wire screw connections on line and load side. |
| Connection Type | Line/Load/Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 90 mm H x 18 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 44.27 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 0.3600 lb |
| Gross Weight per Pack Metric | 0.16 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.2500 in |
| Height [Metric] | 8.2550 cm |
| Length | 3.8000 in |
| Length [Metric] | 9.6520 cm |
| Material | N/A |
| Mounting Type | DIN Rail |
| Number Of Poles | 1 |
| Phase | 1 |
| Returnable | Y |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | SENTRON |
| Temperature Rating | -25 to 55 °C |
| Type | Type HSJ |
| UNSPSC | 39121601 |
| UPC 11 | 75455493233 |
| UPC 12 | 754554932330 |
| Width | 1.2000 in |
| Width [Metric] | 3.0480 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 3 A |
| Interrupt Rating | 14 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| BRANCH CIRCUIT PROTECTORS |
| 1-POLE |
| 40 deg C calibration base (industrial applications) |
| 30 deg C calibration base |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Suitable for reverse feed applications |
| D-trip is designed for high inrush loads. Magnetic trip point is 10 to 20 times the MCB rating |
| 0.75 to 35 mm2 solid and stranded conductors |
| Visible indicator for on and off/trip |
| Touch protection to EN50274 |
| Identical wire screw connections on line and load sides |
| Smaller size than traditional MCCBs |
| 35 mm DIN standard mounting rail |
| Short circuit rating: 14 kA |
