Sentron™ 5SJ4102-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 2 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Sentron™ 5SJ4102-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 2 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
SKU617125
MFGR #5SJ4102-7HG42
Your Cost: $53.23/ea
List: SIEMENS 5SJ4102-7HG42 MCB UL489 1-P 277VAC 2A C-TRIP TYPE NSJ
SIEMENS 5SJ4102-7HG42 MCB UL489 1-P 277VAC 2A C-TRIP TYPE NSJ
Actuator Type Handle Alternate Catalog Number 5SJ4102-7HG42 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4102-7HG42 Connection Identical wire screw connections on line and load side. Connection Type Line/Load/Screw Country of Origin DE Currency USD Dimensions 121 mm H x 18 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 109.92 Gross Volume UOM in Gross Weight Per Pack 0.2300 lb Gross Weight per Pack Metric 0.18 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 3.2500 in Height [Metric] 8.2550 cm Length 4.0000 in Length [Metric] 10.1600 cm Material N/A Mounting Type DIN Rail Number Of Poles 1 Phase 1 Returnable Y Standard UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand SENTRON Temperature Rating -25 to 55 °C Type Type NSJ UNSPSC 39121601 UPC 11 75455495946 UPC 12 754554959467 Width 1.9000 in Width [Metric] 4.8260 cm Wire Size 14 to 4 AWG Stock Status NORMALLY STOCKED Brand Siemens Manufacturer Siemens Amperage Rating 2 A Interrupt Rating 14 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC BRANCH CIRCUIT PROTECTORS 1-POLE Can be used for field wiring applications 14 to 4 AWG copper only Visible indicator for on and off/trip
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4102-7HG42 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4102-7HG42 |
| Connection | Identical wire screw connections on line and load side. |
| Connection Type | Line/Load/Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 121 mm H x 18 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 109.92 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 0.2300 lb |
| Gross Weight per Pack Metric | 0.18 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.2500 in |
| Height [Metric] | 8.2550 cm |
| Length | 4.0000 in |
| Length [Metric] | 10.1600 cm |
| Material | N/A |
| Mounting Type | DIN Rail |
| Number Of Poles | 1 |
| Phase | 1 |
| Returnable | Y |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | SENTRON |
| Temperature Rating | -25 to 55 °C |
| Type | Type NSJ |
| UNSPSC | 39121601 |
| UPC 11 | 75455495946 |
| UPC 12 | 754554959467 |
| Width | 1.9000 in |
| Width [Metric] | 4.8260 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NORMALLY STOCKED |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 2 A |
| Interrupt Rating | 14 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| BRANCH CIRCUIT PROTECTORS |
| 1-POLE |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Visible indicator for on and off/trip |
