Siemens
Sentron™ 5SJ4102-7HG40 Miniature Circuit Breaker, 240 VAC/60 VDC, 0.5 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Siemens
Sentron™ 5SJ4102-7HG40 Miniature Circuit Breaker, 240 VAC/60 VDC, 0.5 A, 14 kA Interrupt, 1 Pole, Thermal Magnetic Trip
SKU362534
MFGR #5SJ4102-7HG40
Your Cost: $48.47/ea
List: SIEMENS 5SJ4102-7HG40 1P 2A C-TRIP CB
SIEMENS 5SJ4102-7HG40 1P 2A C-TRIP CB
Adapter Rating N/A Alternate Catalog Number 5SJ4102-7HG40 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4102-7HG40 Class C Connection Identical wire screw connections on line and load side. Country of Origin DE Currency USD Element N/A EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 64.16 Gross Volume UOM in Gross Weight Per Pack 0.3700 lb Gross Weight per Pack Metric 0.17 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 3.2500 in Height [Metric] 8.2550 cm Length 7.4500 in Length [Metric] 18.9230 cm Material N/A Mounting On standard mounting rail (DIN 35mm) Number Of Poles 1 Response Time N/A Hz Returnable Y Short Circuit Rating 14kA Size N/A Standard UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 Standards CSA 22.2 No. 5-02, CE Certified, cULus Listed, EN 60898, EN 60947-2, HACR Rated, RoHS Compliant, UL 489, UL File No. E243414 Sub Brand SENTRON Type HSJ Type Of Indicators N/A UNSPSC 39121601 UPC 11 75455493221 UPC 12 754554932217 Width 2.6500 in Width [Metric] 6.7310 cm Stock Status NORMALLY STOCKED Brand Siemens Manufacturer Siemens Interrupt Rating 14kA V Voltage Rating 240 V BRANCH CIRCUIT PROTECTORS 1-POLE 40 deg C calibration base (industrial applications) 30 deg C calibration base Can be used for field wiring applications, 14 - 4 AWG, copper (Cu) only Suitable for reverse feed applications C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating 0.75 to 35 mm2 solid and stranded conductors Visible indicator for ON and OFF/trip Touch protection to EN50274 Identical wire screw connections on line and load sides Smaller size than traditional MCCBs 35 mm DIN standard mounting rail
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Adapter Rating | N/A |
| Alternate Catalog Number | 5SJ4102-7HG40 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4102-7HG40 |
| Class | C |
| Connection | Identical wire screw connections on line and load side. |
| Country of Origin | DE |
| Currency | USD |
| Element | N/A |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 64.16 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 0.3700 lb |
| Gross Weight per Pack Metric | 0.17 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.2500 in |
| Height [Metric] | 8.2550 cm |
| Length | 7.4500 in |
| Length [Metric] | 18.9230 cm |
| Material | N/A |
| Mounting | On standard mounting rail (DIN 35mm) |
| Number Of Poles | 1 |
| Response Time | N/A Hz |
| Returnable | Y |
| Short Circuit Rating | 14kA |
| Size | N/A |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Standards | CSA 22.2 No. 5-02, CE Certified, cULus Listed, EN 60898, EN 60947-2, HACR Rated, RoHS Compliant, UL 489, UL File No. E243414 |
| Sub Brand | SENTRON |
| Type | HSJ |
| Type Of Indicators | N/A |
| UNSPSC | 39121601 |
| UPC 11 | 75455493221 |
| UPC 12 | 754554932217 |
| Width | 2.6500 in |
| Width [Metric] | 6.7310 cm |
| Stock Status | NORMALLY STOCKED |
| Brand | Siemens |
| Manufacturer | Siemens |
| Interrupt Rating | 14kA V |
| Voltage Rating | 240 V |
| BRANCH CIRCUIT PROTECTORS |
| 1-POLE |
| 40 deg C calibration base (industrial applications) |
| 30 deg C calibration base |
| Can be used for field wiring applications, 14 - 4 AWG, copper (Cu) only |
| Suitable for reverse feed applications |
| C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating |
| 0.75 to 35 mm2 solid and stranded conductors |
| Visible indicator for ON and OFF/trip |
| Touch protection to EN50274 |
| Identical wire screw connections on line and load sides |
| Smaller size than traditional MCCBs |
| 35 mm DIN standard mounting rail |
