Schneider ElectricAltivar 71 ATV71HD18N4 Variable Speed Drive, 380/480 VAC, 41 A, 25 hp, 9.06 in W x 8.39 in D
AC Drives
298172
MFG #: ATV71HD18N4
Schneider Electric
6064.58000
/ ea
Schneider Electric ATV71HD18N4 SPEED DRIVE, 25HP, 460V, ATV71,18kW,3 phases,3-Phase,3-Phase,400/480VAC,Altivar 71,Altivar 71,IP20,Modbus-CANopen,Modbus-CANopen,complex, high-power machines,variable speed drive
- Brochure URL - 18fbd6a936770f3b130b34af1934180775930a17.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_2fd08ee500428af679e6a483bd90a358f4d5d4a1f7b67a205ddf01d827485c20.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - 8f7411384b740518f82d79dae86a8e445de83767.pdf(Computer~Aided [CAD|BIM] Model URL)
- Owners Manual URL - Schneider_Electric_ATV61HC11N4_Manual.pdf(Owners Manual URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - 749797d1de9c6f10301873a0dea54b5650bf5a8d.pdf(Spec Sheet URL)
- Tech Bulletin URL - 7855e2dbfa3f9603a0a01e5c645d9054a3e16ebe.pdf(Tech Bulletin URL)
- Tech Drawing URL - 3471f3a043144e90e8a8e52b1f97c56664a521bc(Tech Drawing URL)
- User Manual URL - 89d1333205d08274650a7939d5833cc950c2f599.pdf(User Manual URL)
- Video - https://www.youtube.com/embed/tQdCxRMVtUg(Video)
- Applications
- Features
| 18.5 KW, 3 PHASE 380...480 V,25 HP, 3 PHASE 380...480 V,COMPLEX, HIGH-POWER MACHINES,SYNCHRONOUS MOTORS-ASYNCHRONOUS MOTORS |
| ADJUSTABLE PI REGULATOR,AGAINST EXCEEDING LIMIT SPEED DRIVE-SHORT-CIRCUIT BETWEEN MOTOR PHASES DRIVE-THERMAL PROTECTION DRIVE-MOTOR PHASE BREAK MOTOR-POWER REMOVAL MOTOR-THERMAL PROTECTION MOTOR-AGAINST INPUT PHASE LOSS DRIVE-BREAK ON THE CONTROL CIRCUIT DRIVE-INPUT PHASE BREAKS DRIVE-LINE SUPPLY OVERVOLTAGE DRIVE-LINE SUPPLY UNDERVOLTAGE DRIVE-OVERCURRENT BETWEEN OUTPUT PHASES AND EARTH DRIVE-OVERHEATING PROTECTION DRIVE-OVERVOLTAGES ON THE DC BUS DRIVE,INTERNAL SUPPLY FOR REFERENCE POTENTIOMETER (1 TO 10 KOHM) 10.5 V DC +/- 5 , <10 MA OVERLOAD AND SHORT-CIRCUIT PROTECTION-INTERNAL SUPPLY 24 V DC 21-27 V), <200 MA OVERLOAD AND SHORT-CIRCUIT PROTECTION,TERMINAL 2.5 MMA², AWG 14 AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)-TERMINAL 35 MMA², AWG 2 L1/R, L2/S, L3/T, U/T1, V/T2, W/T3, PC/-, PO, PA/+, PA, PB),VOLTAGE/FREQUENCY RATIO (2 OR 5 POINTS)-SENSORLESS FLUX VECTOR CONTROL (SFVC) (VOLTAGE OR CURRENT VECTOR)-FLUX VECTOR CONTROL (FVC) WITH SENSOR (CURRENT VECTOR)-ENA (ENERGY ADAPTATION) SYSTEM FOR UNBALANCED LOADS |
| Frequency inverters for 3-phase synchronous and asynchronous motors |
| Speed regulation by flux vector control with or without sensor |
| Protection of motor and of drive |
| Exceptional performance, advanced functions |
| Altivar® 71 provides ingenious solutions for all your particular requirements |
| Integrated EMC filter Class A |
| Constant torque |
| Graphic terminal plain text, navigation button, configurable function keys, "Simply Start" menu |
| Modbus, CANopen communication port protocol |
| 1 to 1000 in closed loop mode with encoder feedback, from 1 to 100 in open loop mode speed range |
