Schneider Electric ZB4BK1553 Harmony™ XB4 Non-Illuminated Selector Switch Operator, 22 mm, Round Standard Lever Operator, 3 Positions
Custom_Product_Images_Illustration
Schneider Electric ZB4BK1553 Harmony™ XB4 Non-Illuminated Selector Switch Operator, 22 mm, Round Standard Lever Operator, 3 Positions
SKU100159
MFGR #ZB4BK1553
Your Cost: $32.24/ea
List: Schneider Electric ZB4BK1553 3POS ILLUM SPRING RET SELECTOR YELLOW,22 mm,illum select switch,Harmony XB4,IP 65,Illuminated Standard Knob 3 Position,NEMA 1/2/3/4/4X/13,UL Listed File Number E164353 CCN NKCR - CSA Certified File Number LR44087 Class 321103 - CE Marked,chromium plated metal,head for illuminated selector switch,head for illuminated selector switch,illum select switch,orange,spring return to centre
Schneider Electric ZB4BK1553 3POS ILLUM SPRING RET SELECTOR YELLOW,22 mm,illum select switch,Harmony XB4,IP 65,Illuminated Standard Knob 3 Position,NEMA 1/2/3/4/4X/13,UL Listed File Number E164353 CCN NKCR - CSA Certified File Number LR44087 Class 321103 - CE Marked,chromium plated metal,head for illuminated selector switch,head for illuminated selector switch,illum select switch,orange,spring return to centre
Action SPRING RETURN TO CENTRE Actuator To centre spring return;Orange standard handle;3 positions +/- 45° Alternate Catalog Number ZB4BK1553 Application Integral LED ARRA Compliant N Bezel|Housing Chromium Plated Metal Brand Schneider Electric Buy American Compliant N Catalog Number ZB4BK1553 Color Orange Contact Mode Momentary Country of Origin FR Currency USD Enclosure NEMA 13-NEMA 4X Enclosure Type NEMA 1/2/3/4/4X/13/IP65 Environmental Conditions IP 65 EU RoHS Indicator Y Gross Volume Per Pack 4.79 Gross Volume per Pack Metric 78.49 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0900 lb Gross Weight per Pack Metric 41.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8538908180 Height 3.4000 in Height [Metric] 3.4000 cm Indicator ORANGE Item Group 22468 Lamp Type LED Length 5.5000 in Length [Metric] 5.5000 cm Manufacturer Schneider Electric Material Chromium plated metal Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=657500&lang=en-us Mounting Type Front Number of Positions 3 Operating Temperature -40-70 A°C Operator Type Standard Knob/Spring Return Returnable Y Series XB4 Size 22 mm Stock Status NONSTOCK Sub Brand ZB4 Substitute Product Catalog Number ZB4BZ009 Temperature Rating -40 to 158 °F Terminal Type Screw/Clamp Throw 45 deg Left/Center/Right Type Integral Illuminated Round UNSPSC 39122216 UPC 11 78590189100 UPC 12 785901891000 Warranty Description Contractual Warranty:18 months Width 5.4000 in Width [Metric] 5.4000 cm Integral LED CHROMIUM PLATED METAL,HEAD FOR ILLUMINATED SELECTOR SWITCH
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | SPRING RETURN TO CENTRE |
| Actuator | To centre spring return;Orange standard handle;3 positions +/- 45° |
| Alternate Catalog Number | ZB4BK1553 |
| Application | Integral LED |
| ARRA Compliant | N |
| Bezel|Housing | Chromium Plated Metal |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | ZB4BK1553 |
| Color | Orange |
| Contact Mode | Momentary |
| Country of Origin | FR |
| Currency | USD |
| Enclosure | NEMA 13-NEMA 4X |
| Enclosure Type | NEMA 1/2/3/4/4X/13/IP65 |
| Environmental Conditions | IP 65 |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 4.79 |
| Gross Volume per Pack Metric | 78.49 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0900 lb |
| Gross Weight per Pack Metric | 41.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8538908180 |
| Height | 3.4000 in |
| Height [Metric] | 3.4000 cm |
| Indicator | ORANGE |
| Item Group | 22468 |
| Lamp Type | LED |
| Length | 5.5000 in |
| Length [Metric] | 5.5000 cm |
| Manufacturer | Schneider Electric |
| Material | Chromium plated metal |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=657500&lang=en-us |
| Mounting Type | Front |
| Number of Positions | 3 |
| Operating Temperature | -40-70 A°C |
| Operator Type | Standard Knob/Spring Return |
| Returnable | Y |
| Series | XB4 |
| Size | 22 mm |
| Stock Status | NONSTOCK |
| Sub Brand | ZB4 |
| Substitute Product Catalog Number | ZB4BZ009 |
| Temperature Rating | -40 to 158 °F |
| Terminal Type | Screw/Clamp |
| Throw | 45 deg Left/Center/Right |
| Type | Integral Illuminated Round |
| UNSPSC | 39122216 |
| UPC 11 | 78590189100 |
| UPC 12 | 785901891000 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 5.4000 in |
| Width [Metric] | 5.4000 cm |
| Integral LED |
| CHROMIUM PLATED METAL,HEAD FOR ILLUMINATED SELECTOR SWITCH |
