Schneider Electric TeSys™ K LC1K IEC Contactor LC1K0901G7, 120 VAC Coil, 0.375 Max Load, 3NO, 3 Poles
Custom_Product_Images_Illustration
Schneider Electric TeSys™ K LC1K IEC Contactor LC1K0901G7, 120 VAC Coil, 0.375 Max Load, 3NO, 3 Poles
SKU515533
MFGR #LC1K0901G7
Your Cost: $75.54/ea
Schneider Electric LC1K0901G7 CONTACTOR 575VAC 9AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,120 V AC 50/60 Hz,3 NO,3P,LC1K,contactor,LC1K,motor control-resistive load,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked,rail-plate
Schneider Electric LC1K0901G7 CONTACTOR 575VAC 9AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,120 V AC 50/60 Hz,3 NO,3P,LC1K,contactor,LC1K,motor control-resistive load,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked,rail-plate
Alternate Catalog Number LC1K0901G7 Application Motor control;resistive load ARRA Compliant N Brand Schneider Electric Buy American Compliant N Catalog Number LC1K0901G7 Coil Power Rating 4 kW Coil Voltage 120 VAC Contact Configuration 3NO Contact Rating 9 A at 575 VAC Country of Origin US Currency USD Dimensions 2.28 in H x 1.17 in W x 2.24 in D Enclosure Type Open EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 11.86 Gross Volume per Pack Metric 194.35 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.4000 lb Gross Weight per Pack Metric 181.50 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536490065 Height 4.9000 in Height [Metric] 6.6000 cm Item Group 22326 Length 6.8000 in Length [Metric] 6.2000 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622748&lang=en-us Maximum Load Current 20 A Mounting PLATE-RAIL Mounting Type Surface Number of Auxiliary Contacts 1NC Number Of Poles 3 Operating Cycles 10000000 Operating Temperature -13 to 122 Returnable Y Series K-Line LC1K Size 45 MM,57 MM,58 MM Standard BS 5424-IEC 60947-NF C 63-110-VDE 0660,IP2X VDE 0106,UL-CSA,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 Stock Status NONSTOCK Sub Brand TESYS K Substitute Product Catalog Number LA1KN04 Terminal Type Screw/Clamp Type CONTACTOR UNSPSC 39121529 UPC 11 78590166681 UPC 12 785901666813 Warranty Description Contractual Warranty:18 months Width 6.2000 in Width [Metric] 4.8000 cm Motor control;resistive load 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT 8 kV rated impulse withstand voltage III overvoltage category 20 A at 122 deg F power circuit, 10 A at 122 deg F signaling circuit conventional-free air thermal current 110 A at 415 V, 110 A at 440 V, 80 A at 500 V, 110 A at 220 to 230 V, 110 A at 380 to 400 V, 70 A at 660 to 690 V conforming to IEC 60947 rated breaking capacity 25 A gG at 440 V power circuit, 25 A aM power circuit associated fuse rating 3 mOhm at 50 Hz - Ith 20 A power circuit average impedance 600 VAC power circuit conforming to CSA C22.2 No 14/690 VAC power circuit conforming to IEC 60947-4-1/600 VAC power circuit conforming to UL 508 rated insulation voltage 1.3 N-m on screw clamp terminals with screwdriver Philips® No 2/1.3 N-m on screw clamp terminals with screwdriver flat 6 mm tightening torque 30 VA at 68 deg F (20 deg C) inrush power 4.5 VA at 68 deg F (20 deg C) hold-in power consumption 1.3 W heat dissipation 3600 cycles/hr operating rate 10 to 20 ms coil de-energization and NO opening, 10 to 20 ms coil energization and NO closing operating time TC protective treatment 6561.68 ft (2000 m) without derating in temperature operating altitude <=400 Hz signaling circuit frequency 5 mA signaling circuit minimum switching current 17 V signaling circuit minimum switching voltage 2.2 kW at 400 VAC 50/60 Hz AC-4, 2.2 kW at 220 to 230 VAC 50/60 Hz AC-3, 4 kW at 380 to 415 VAC 50/60 Hz AC-3 4 kW at 440 VAC 50/60 Hz AC-3, 4 kW at 480 VAC 50/60 Hz AC-3, 4 kW at 500 to 600 VAC 50/60 Hz AC-3, 4 kW at 660 to 690 VAC 50/60 Hz AC 3-phase power rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LC1K0901G7 |
| Application | Motor control;resistive load |
| ARRA Compliant | N |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | LC1K0901G7 |
| Coil Power Rating | 4 kW |
| Coil Voltage | 120 VAC |
| Contact Configuration | 3NO |
| Contact Rating | 9 A at 575 VAC |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 2.28 in H x 1.17 in W x 2.24 in D |
| Enclosure Type | Open |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 11.86 |
| Gross Volume per Pack Metric | 194.35 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.4000 lb |
| Gross Weight per Pack Metric | 181.50 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 4.9000 in |
| Height [Metric] | 6.6000 cm |
| Item Group | 22326 |
| Length | 6.8000 in |
| Length [Metric] | 6.2000 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622748&lang=en-us |
| Maximum Load Current | 20 A |
| Mounting | PLATE-RAIL |
| Mounting Type | Surface |
| Number of Auxiliary Contacts | 1NC |
| Number Of Poles | 3 |
| Operating Cycles | 10000000 |
| Operating Temperature | -13 to 122 |
| Returnable | Y |
| Series | K-Line LC1K |
| Size | 45 MM,57 MM,58 MM |
| Standard | BS 5424-IEC 60947-NF C 63-110-VDE 0660,IP2X VDE 0106,UL-CSA,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 |
| Stock Status | NONSTOCK |
| Sub Brand | TESYS K |
| Substitute Product Catalog Number | LA1KN04 |
| Terminal Type | Screw/Clamp |
| Type | CONTACTOR |
| UNSPSC | 39121529 |
| UPC 11 | 78590166681 |
| UPC 12 | 785901666813 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 6.2000 in |
| Width [Metric] | 4.8000 cm |
| Motor control;resistive load |
| 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT |
| 8 kV rated impulse withstand voltage |
| III overvoltage category |
| 20 A at 122 deg F power circuit, 10 A at 122 deg F signaling circuit conventional-free air thermal current |
| 110 A at 415 V, 110 A at 440 V, 80 A at 500 V, 110 A at 220 to 230 V, 110 A at 380 to 400 V, 70 A at 660 to 690 V conforming to IEC 60947 rated breaking capacity |
| 25 A gG at 440 V power circuit, 25 A aM power circuit associated fuse rating |
| 3 mOhm at 50 Hz - Ith 20 A power circuit average impedance |
| 600 VAC power circuit conforming to CSA C22.2 No 14/690 VAC power circuit conforming to IEC 60947-4-1/600 VAC power circuit conforming to UL 508 rated insulation voltage |
| 1.3 N-m on screw clamp terminals with screwdriver Philips® No 2/1.3 N-m on screw clamp terminals with screwdriver flat 6 mm tightening torque |
| 30 VA at 68 deg F (20 deg C) inrush power |
| 4.5 VA at 68 deg F (20 deg C) hold-in power consumption |
| 1.3 W heat dissipation |
| 3600 cycles/hr operating rate |
| 10 to 20 ms coil de-energization and NO opening, 10 to 20 ms coil energization and NO closing operating time |
| TC protective treatment |
| 6561.68 ft (2000 m) without derating in temperature operating altitude |
| <=400 Hz signaling circuit frequency |
| 5 mA signaling circuit minimum switching current |
| 17 V signaling circuit minimum switching voltage |
| 2.2 kW at 400 VAC 50/60 Hz AC-4, 2.2 kW at 220 to 230 VAC 50/60 Hz AC-3, 4 kW at 380 to 415 VAC 50/60 Hz AC-3 |
| 4 kW at 440 VAC 50/60 Hz AC-3, 4 kW at 480 VAC 50/60 Hz AC-3, 4 kW at 500 to 600 VAC 50/60 Hz AC-3, 4 kW at 660 to 690 VAC 50/60 Hz AC 3-phase power rating |
