Schneider Electric Square D™ M9F15220 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 125 VDC, 20 A, 30 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Schneider Electric Square D™ M9F15220 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 125 VDC, 20 A, 30 kA Interrupt, 2 Poles, Thermal Magnetic Trip
SKU1311535
MFGR #M9F15220
Your Cost: $382.22/ea
List: Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 125 VDC, 20 A, 50/60 Hz Frequency, 30 kA Interrupt, Thermal Magnetic Trip, 2 Pole, Toggle Actuator, Flexible/Rigid Tunnel Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 36 mm W x 72 mm D x 81 mm H Dimensions, Gray
Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 125 VDC, 20 A, 50/60 Hz Frequency, 30 kA Interrupt, Thermal Magnetic Trip, 2 Pole, Toggle Actuator, Flexible/Rigid Tunnel Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 36 mm W x 72 mm D x 81 mm H Dimensions, Gray
Actuator Toggle Alternate Catalog Number M9F15220 Application HVAC, Lift, Crane and Hoisting, Pumping, Genset, Semiconductor Industry, Packaging, Conveying and Telecom Applications ARRA Compliant N Buy American Compliant N Catalog Number M9F15220 Connection Tunnel type terminal top or bottom) 1-25 mm² - rigid;tunnel type terminal top or bottom) 1-25 mm² - flexible;tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule Country of Origin FR Currency USD EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.4640 lb Gross Weight per Pack Metric 211.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200020 Height 2.92 in Height [Metric] 7.5000 cm Length 3.32 in Length [Metric] 8.5000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=244804337&lang=en-us Number Of Poles 2 Returnable N Standard EN/IEC 60947-2;EAC;CCC Sub Brand Multi9 C60;C60H Substitute Product Catalog Number A9XPH257 Type Miniature circuit-breaker UNSPSC 39121603 UPC 11 36064805776 Upsell Product Catalog Number M9A26948 Width 1.40 in Width [Metric] 3.6000 cm Stock Status NONSTOCK Brand Schneider Electric Manufacturer Schneider Electric Trip Type THERMAL-MAGNETIC HVAC, Lift, Crane and Hoisting, Pumping, Genset, Semiconductor Industry, Packaging, Conveying and Telecom Applications ON/OFF indication Multi 9™ is a range of DIN rail modular devices, a solution offering great performance Multi 9™ range is a Schneider Electric global offer dedicated to equipment manufacturers (OEMs), meeting all global standards for industry applications Designed to meet your needs for all types of machines and offering a wide range of modular devices, it provides protection, signaling functions and accessories With its wide range, new performances and the multiple choices of field installable accessories, Multi 9™ allows you to adapt easily to any configuration any time Multi 9™ fits perfectly in Schneider Electric solutions, allowing you to build your panel with the global specialist in energy management and automation Optimized - small footprint to reduce your panel size, cost effective, less commercial references Renowned quality - world leader's proven technology and experience Benefits to be completed 25 kA at 125 VDC, 30 kA at 240 VAC, 15 kA at 415 VAC and 10 kA at 440 VAC 30 kA at 240 VAC 30 kA at 240 VAC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Toggle |
| Alternate Catalog Number | M9F15220 |
| Application | HVAC, Lift, Crane and Hoisting, Pumping, Genset, Semiconductor Industry, Packaging, Conveying and Telecom Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | M9F15220 |
| Connection | Tunnel type terminal top or bottom) 1-25 mm² - rigid;tunnel type terminal top or bottom) 1-25 mm² - flexible;tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule |
| Country of Origin | FR |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.4640 lb |
| Gross Weight per Pack Metric | 211.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 2.92 in |
| Height [Metric] | 7.5000 cm |
| Length | 3.32 in |
| Length [Metric] | 8.5000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=244804337&lang=en-us |
| Number Of Poles | 2 |
| Returnable | N |
| Standard | EN/IEC 60947-2;EAC;CCC |
| Sub Brand | Multi9 C60;C60H |
| Substitute Product Catalog Number | A9XPH257 |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| UPC 11 | 36064805776 |
| Upsell Product Catalog Number | M9A26948 |
| Width | 1.40 in |
| Width [Metric] | 3.6000 cm |
| Stock Status | NONSTOCK |
| Brand | Schneider Electric |
| Manufacturer | Schneider Electric |
| Trip Type | THERMAL-MAGNETIC |
| HVAC, Lift, Crane and Hoisting, Pumping, Genset, Semiconductor Industry, Packaging, Conveying and Telecom Applications |
| ON/OFF indication |
| Multi 9™ is a range of DIN rail modular devices, a solution offering great performance |
| Multi 9™ range is a Schneider Electric global offer dedicated to equipment manufacturers (OEMs), meeting all global standards for industry applications |
| Designed to meet your needs for all types of machines and offering a wide range of modular devices, it provides protection, signaling functions and accessories |
| With its wide range, new performances and the multiple choices of field installable accessories, Multi 9™ allows you to adapt easily to any configuration any time |
| Multi 9™ fits perfectly in Schneider Electric solutions, allowing you to build your panel with the global specialist in energy management and automation |
| Optimized - small footprint to reduce your panel size, cost effective, less commercial references |
| Renowned quality - world leader's proven technology and experience |
| Benefits to be completed |
| 25 kA at 125 VDC, 30 kA at 240 VAC, 15 kA at 415 VAC and 10 kA at 440 VAC |
| 30 kA at 240 VAC |
| 30 kA at 240 VAC |
