Square D™
Schneider Electric PowerPact™ JDL36250T Molded Case Circuit Breaker, 600 VAC, 250 A, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Schneider Electric PowerPact™ JDL36250T Molded Case Circuit Breaker, 600 VAC, 250 A, 3 Poles, Thermal Magnetic Trip
SKU696175
MFGR #JDL36250T
Your Cost: $4,133.02/ea
Schneider Electric JDL36250T MOLDED CASE CIRCUIT BREAKER 600V 250A
Schneider Electric JDL36250T MOLDED CASE CIRCUIT BREAKER 600V 250A
Actuator Type Toggle Alternate Catalog Number JDL36250T ARRA Compliant N Buy American Compliant N Catalog Number JDL36250T Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 4.5000 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01110 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425267&lang=en-us Mounting Type Surface Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable N Standard CCC-CE-UL LISTED-IEC-CSA Temperature Rating 104 °F Trip Range 1250 to 2500 A Type 80% Rated UNSPSC 39121616 UPC 11 78590169776 UPC 12 785901697763 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 3/0 AWG to 350 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 250 A Interrupt Rating 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC TRIP UNIT FIELD inSTALLABLE Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | JDL36250T |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JDL36250T |
| Connection | AWG 3/0...350 KCMIL ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | J Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.5000 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01110 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425267&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | N |
| Standard | CCC-CE-UL LISTED-IEC-CSA |
| Temperature Rating | 104 °F |
| Trip Range | 1250 to 2500 A |
| Type | 80% Rated |
| UNSPSC | 39121616 |
| UPC 11 | 78590169776 |
| UPC 12 | 785901697763 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 3/0 AWG to 350 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 250 A |
| Interrupt Rating | 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| TRIP UNIT FIELD inSTALLABLE |
| Rated current from 70 to 250 A |
| Breaking capacity from 18 to 65 kA at 480 VAC |
| Common accessories and auxiliaries with other PowerPact™ frames |
| 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating |
