Square D™
Schneider Electric PowerPact™ HJL36125SA Molded Case Circuit Breaker, 600 VAC, 125 A, 3 Poles, Shunt/Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Schneider Electric PowerPact™ HJL36125SA Molded Case Circuit Breaker, 600 VAC, 125 A, 3 Poles, Shunt/Thermal Magnetic Trip
SKU514868
MFGR #HJL36125SA
Call For Price
List: Schneider Electric HJL36125SA MOLDED CASE CIRCUIT BREAKER 600V 125A
Schneider Electric HJL36125SA MOLDED CASE CIRCUIT BREAKER 600V 125A
Actuator Type Toggle Alternate Catalog Number HJL36125SA Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number HJL36125SA Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0227 lb Gross Weight per Pack Metric 2.27 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 CM Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 CM Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423859&lang=en-us Mounting Type Surface/Unit Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable Y Standard CCC-CE-UL LISTED-IEC-CSA Temperature Rating 104 °F Trip Range 900 to 1700 A Type Type HJL UNSPSC 39121601 UPC 11 78590166917 UPC 12 785901669173 Warranty Description Contractual Warranty:18 months Width 18.0000 CM Width [Metric] 18.4150 cm Wire Size 14 to 3/0 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 125 A Interrupt Rating 65/25/100/20 kA Trip Type Shunt/Thermal Magnetic Voltage Rating 600 VAC/250 VDC Distribution UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | HJL36125SA |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HJL36125SA |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0227 lb |
| Gross Weight per Pack Metric | 2.27 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 CM |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 CM |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423859&lang=en-us |
| Mounting Type | Surface/Unit |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | Y |
| Standard | CCC-CE-UL LISTED-IEC-CSA |
| Temperature Rating | 104 °F |
| Trip Range | 900 to 1700 A |
| Type | Type HJL |
| UNSPSC | 39121601 |
| UPC 11 | 78590166917 |
| UPC 12 | 785901669173 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.0000 CM |
| Width [Metric] | 18.4150 cm |
| Wire Size | 14 to 3/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 125 A |
| Interrupt Rating | 65/25/100/20 kA |
| Trip Type | Shunt/Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| Distribution |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
