Schneider Electric LC1K1201B7 CONTACTOR 600VAC 12A
Custom_Product_Images_Illustration
Schneider Electric LC1K1201B7 CONTACTOR 600VAC 12A
SKU609529
MFGR #LC1K1201B7
Your Cost: $111.06/ea
Schneider Electric LC1K1201B7 CONTACTOR 600VAC 12AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,24 V AC 50/60 Hz,3 NO,LC1K,LC1K,motor control-resistive load,Panel,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked
Schneider Electric LC1K1201B7 CONTACTOR 600VAC 12AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,24 V AC 50/60 Hz,3 NO,LC1K,LC1K,motor control-resistive load,Panel,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked
Alternate Catalog Number LC1K1201B7 Application Resistive load;motor control ARRA Compliant N Brand Schneider Electric Buy American Compliant N Catalog Number LC1K1201B7 Coil Power Rating 4 kW at 660 to 690 VAC Coil Voltage 24 VAC Contact Configuration 3NO Contact Rating 20 A 50 A°C POWER CIRCUIT-10 A 50 A°C SIGNALLING CIRCUIT Country of Origin ID Currency USD Dimensions 58 mm H x 45 mm W x 57 mm D Enclosure Type Open EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 11.40 Gross Volume per Pack Metric 186.81 Gross Weight Per Pack 0.4000 lb Gross Weight per Pack Metric 180.70 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536410045 Height 6.6000 in Height [Metric] 4.5000 cm Item Group 22326 Length 6.2000 in Length [Metric] 6.5000 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=623216&lang=en-us Maximum Load Current 12/16/20 A Mounting Panel Mounting Type Panel Number of Auxiliary Contacts 1NC Number Of Poles 3 Operating Cycles 3600 Cycles/hr Returnable Y Series TeSys™ K LC1K Size 3P Standard CSA-UL,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 Stock Status NONSTOCK Sub Brand TESYS K Substitute Product Catalog Number LA1KN11 Terminal Type Screw/Clamp Type Non-Reversing UNSPSC 39121529 UPC 11 78590130410 UPC 12 785901304104 Warranty Description Contractual Warranty:18 months Width 4.8000 in Width [Metric] 6.0000 cm Resistive load;motor control 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT TeSys™ K is one of the smallest contactor offerings in the market The range delivers strong performance for its compact size and promises seamless integration in all applications Simple control systems Zones sensitive to noise, disturbed mains supplies Use compatible with programmable controller outputs - low consumption contactor 3-pole TeSys™ K contactor from Schneider electric for motor applications 5 kW at 400 V, it includes a 24 V 50/60 Hz AC coil and 1NC auxiliary contact
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LC1K1201B7 |
| Application | Resistive load;motor control |
| ARRA Compliant | N |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | LC1K1201B7 |
| Coil Power Rating | 4 kW at 660 to 690 VAC |
| Coil Voltage | 24 VAC |
| Contact Configuration | 3NO |
| Contact Rating | 20 A 50 A°C POWER CIRCUIT-10 A 50 A°C SIGNALLING CIRCUIT |
| Country of Origin | ID |
| Currency | USD |
| Dimensions | 58 mm H x 45 mm W x 57 mm D |
| Enclosure Type | Open |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 11.40 |
| Gross Volume per Pack Metric | 186.81 |
| Gross Weight Per Pack | 0.4000 lb |
| Gross Weight per Pack Metric | 180.70 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536410045 |
| Height | 6.6000 in |
| Height [Metric] | 4.5000 cm |
| Item Group | 22326 |
| Length | 6.2000 in |
| Length [Metric] | 6.5000 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=623216&lang=en-us |
| Maximum Load Current | 12/16/20 A |
| Mounting | Panel |
| Mounting Type | Panel |
| Number of Auxiliary Contacts | 1NC |
| Number Of Poles | 3 |
| Operating Cycles | 3600 Cycles/hr |
| Returnable | Y |
| Series | TeSys™ K LC1K |
| Size | 3P |
| Standard | CSA-UL,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 |
| Stock Status | NONSTOCK |
| Sub Brand | TESYS K |
| Substitute Product Catalog Number | LA1KN11 |
| Terminal Type | Screw/Clamp |
| Type | Non-Reversing |
| UNSPSC | 39121529 |
| UPC 11 | 78590130410 |
| UPC 12 | 785901304104 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 4.8000 in |
| Width [Metric] | 6.0000 cm |
| Resistive load;motor control |
| 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT |
| TeSys™ K is one of the smallest contactor offerings in the market |
| The range delivers strong performance for its compact size and promises seamless integration in all applications |
| Simple control systems |
| Zones sensitive to noise, disturbed mains supplies |
| Use compatible with programmable controller outputs - low consumption contactor |
| 3-pole TeSys™ K contactor from Schneider electric for motor applications |
| 5 kW at 400 V, it includes a 24 V 50/60 Hz AC coil and 1NC auxiliary contact |
