Schneider Electric
Schneider Electric LC1K0601B7 CONTACTOR 600VAC 6AM
Custom_Product_Images_Illustration
Schneider Electric
Schneider Electric LC1K0601B7 CONTACTOR 600VAC 6AM
SKU276169
MFGR #LC1K0601B7
Your Cost: $73.61/ea
Schneider Electric LC1K0601B7 CONTACTOR 600VAC 6AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,24 V AC 50/60 Hz,3 NO,3P,LC1K,contactor,LC1K,motor control,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked,plate-rail
Schneider Electric LC1K0601B7 CONTACTOR 600VAC 6AMP IEC +OPTIONS,10 A at <= 50 deg.C for signalling circuit-20 A at <= 50 deg.C for power circuit,24 V AC 50/60 Hz,3 NO,3P,LC1K,contactor,LC1K,motor control,TeSys,TeSys K,UL Listed File E164862 NLDX2 - CSA Certified File LR43364 Class 3211 04 - IEC Rated 60947 - CE Marked,plate-rail
Alternate Catalog Number LC1K0601B7 Application MOTOR CONTROL ARRA Compliant N Brand Schneider Electric Buy American Compliant N Catalog Number LC1K0601B7 Coil Power Rating 3 kW at 660 to 690 VAC Coil Voltage 24 VAC Contact Configuration 3NO Contact Rating 20 A 50 A°C POWER CIRCUIT-10 A 50 A°C SIGNALLING CIRCUIT Country of Origin ID Currency USD Dimensions 58 mm H x 45 mm W x 57 mm D Enclosure Type Open EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 11.86 Gross Volume per Pack Metric 194.35 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.3900 lb Gross Weight per Pack Metric 178.93 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536490065 Height 6.2000 in Height [Metric] 4.8000 cm Item Group 22326 Length 6.6000 in Length [Metric] 6.5000 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622066&lang=en-us Maximum Load Current 6 A Mounting PLATE-RAIL Mounting Type Plate/Rail Number of Auxiliary Contacts 1NC Number Of Poles 3 Operating Cycles 3600 Cycles/hr Operating Temperature -25 to 50 Returnable Y Series TeSys™ K LC1K Size 45 MM,57 MM,58 MM Standard BS 5424-IEC 60947-NF C 63-110-VDE 0660,IP2X VDE 0106,UL-CSA,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 Stock Status NONSTOCK Sub Brand TeSys K Substitute Product Catalog Number LA1KN04 Terminal Type Screw/Clamp Type Non-Reversing UNSPSC 39121529 UPC 11 78590136883 UPC 12 785901368830 Warranty Description Contractual Warranty:18 months Width 4.8000 in Width [Metric] 6.2000 cm Motor control 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT Simple control systems Zones sensitive to noise, disturbed mains supplies: silent contactor Use compatible with programmable controller outputs - low consumption contactor 3-pole TeSys™ K contactor from Schneider electric for motor applications 2 kW at 400 V, it includes a 24 VAC 50/60 Hz AC coil and 1NC auxiliary contact
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LC1K0601B7 |
| Application | MOTOR CONTROL |
| ARRA Compliant | N |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | LC1K0601B7 |
| Coil Power Rating | 3 kW at 660 to 690 VAC |
| Coil Voltage | 24 VAC |
| Contact Configuration | 3NO |
| Contact Rating | 20 A 50 A°C POWER CIRCUIT-10 A 50 A°C SIGNALLING CIRCUIT |
| Country of Origin | ID |
| Currency | USD |
| Dimensions | 58 mm H x 45 mm W x 57 mm D |
| Enclosure Type | Open |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 11.86 |
| Gross Volume per Pack Metric | 194.35 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.3900 lb |
| Gross Weight per Pack Metric | 178.93 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 6.2000 in |
| Height [Metric] | 4.8000 cm |
| Item Group | 22326 |
| Length | 6.6000 in |
| Length [Metric] | 6.5000 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622066&lang=en-us |
| Maximum Load Current | 6 A |
| Mounting | PLATE-RAIL |
| Mounting Type | Plate/Rail |
| Number of Auxiliary Contacts | 1NC |
| Number Of Poles | 3 |
| Operating Cycles | 3600 Cycles/hr |
| Operating Temperature | -25 to 50 |
| Returnable | Y |
| Series | TeSys™ K LC1K |
| Size | 45 MM,57 MM,58 MM |
| Standard | BS 5424-IEC 60947-NF C 63-110-VDE 0660,IP2X VDE 0106,UL-CSA,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 |
| Stock Status | NONSTOCK |
| Sub Brand | TeSys K |
| Substitute Product Catalog Number | LA1KN04 |
| Terminal Type | Screw/Clamp |
| Type | Non-Reversing |
| UNSPSC | 39121529 |
| UPC 11 | 78590136883 |
| UPC 12 | 785901368830 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 4.8000 in |
| Width [Metric] | 6.2000 cm |
| Motor control |
| 20 A AT <= 50 °C FOR POWER CIRCUIT-10 A AT <= 50 °C FOR SIGNALLING CIRCUIT |
| Simple control systems |
| Zones sensitive to noise, disturbed mains supplies: silent contactor |
| Use compatible with programmable controller outputs - low consumption contactor |
| 3-pole TeSys™ K contactor from Schneider electric for motor applications |
| 2 kW at 400 V, it includes a 24 VAC 50/60 Hz AC coil and 1NC auxiliary contact |
