Schneider Electric CA2KN40F7 CONTROL RELAY 600VAC
Custom_Product_Images_Illustration
Schneider Electric CA2KN40F7 CONTROL RELAY 600VAC
SKU35408
MFGR #CA2KN40F7
Your Cost: $48.41/ea
Schneider Electric CA2KN40F7 CONTROL RELAY 600VAC 10AMP IEC +OPTIONS,-25...50 deg.C,10 A at <= 50 deg.C,110VAC,4 NO,IP2x,Screw Clamp,TeSys,UL Listed File Number 164353 CCN NKCR - CSA Certified File Number LR43364 Class 3211 03 - CE Marked,control circuit,control relay,rail-plate
Schneider Electric CA2KN40F7 CONTROL RELAY 600VAC 10AMP IEC +OPTIONS,-25...50 deg.C,10 A at <= 50 deg.C,110VAC,4 NO,IP2x,Screw Clamp,TeSys,UL Listed File Number 164353 CCN NKCR - CSA Certified File Number LR43364 Class 3211 03 - CE Marked,control circuit,control relay,rail-plate
Alternate Catalog Number CA2KN40F7 Amperage Rating 10 A Application Control circuit ARRA Compliant N Brand Schneider Electric Buy American Compliant N Catalog Number CA2KN40F7 Coil 110 V AC 50/60 Hz Coil Voltage 110 VAC Contact Configuration 4 NO Contact Form 4NO Country of Origin ID Currency USD Dimensions 2.28 in H x 1.77 in W x 2.24 in D Enclosure IP2X Enclosure Type IP2X EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 11.40 Gross Volume per Pack Metric 186.81 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.3900 lb Gross Weight per Pack Metric 179.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536490075 Height 4.8000 in Height [Metric] 4.8000 cm Item Group 22371 Length 6.6000 in Length [Metric] 6.6000 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=595880&lang=en-us Mounting Rail;plate Mounting Type Plate/Rail Number Of Poles 4 Operating Temperature -25-50 A°C Power Rating 4.5/30 VA Returnable Y Series TeSys™ K Size 2.24 in Standard CSA-UL,IP2X,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 Stock Status NONSTOCK Sub Brand TESYS Substitute Product Catalog Number LA1KN40 Temperature Rating -25 to 50 °C Terminal Type Screw/Clamp Type Control relay UNSPSC 39122331 UPC 11 78590199300 UPC 12 785901993001 Warranty Description Contractual Warranty:18 months Width 6.3000 in Width [Metric] 6.3000 cm Control circuit 30 VA inrush and 4.5 VA hold-in power rating Mounting on 35 mm DIN3 track or 4 screw direct mounting Screws in open "ready-to-tighten" position
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | CA2KN40F7 |
| Amperage Rating | 10 A |
| Application | Control circuit |
| ARRA Compliant | N |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | CA2KN40F7 |
| Coil | 110 V AC 50/60 Hz |
| Coil Voltage | 110 VAC |
| Contact Configuration | 4 NO |
| Contact Form | 4NO |
| Country of Origin | ID |
| Currency | USD |
| Dimensions | 2.28 in H x 1.77 in W x 2.24 in D |
| Enclosure | IP2X |
| Enclosure Type | IP2X |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 11.40 |
| Gross Volume per Pack Metric | 186.81 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.3900 lb |
| Gross Weight per Pack Metric | 179.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536490075 |
| Height | 4.8000 in |
| Height [Metric] | 4.8000 cm |
| Item Group | 22371 |
| Length | 6.6000 in |
| Length [Metric] | 6.6000 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=595880&lang=en-us |
| Mounting | Rail;plate |
| Mounting Type | Plate/Rail |
| Number Of Poles | 4 |
| Operating Temperature | -25-50 A°C |
| Power Rating | 4.5/30 VA |
| Returnable | Y |
| Series | TeSys™ K |
| Size | 2.24 in |
| Standard | CSA-UL,IP2X,V1 UL 94-REQUIREMENT 2 NF F 16-101-REQUIREMENT 2 NF F 16-102 |
| Stock Status | NONSTOCK |
| Sub Brand | TESYS |
| Substitute Product Catalog Number | LA1KN40 |
| Temperature Rating | -25 to 50 °C |
| Terminal Type | Screw/Clamp |
| Type | Control relay |
| UNSPSC | 39122331 |
| UPC 11 | 78590199300 |
| UPC 12 | 785901993001 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 6.3000 in |
| Width [Metric] | 6.3000 cm |
| Control circuit |
| 30 VA inrush and 4.5 VA hold-in power rating |
| Mounting on 35 mm DIN3 track or 4 screw direct mounting |
| Screws in open "ready-to-tighten" position |
