- Features
H10F manufacturer grade |
0 deg body half taper |
Axial concentric coolant entry on circle |
20 bar coolant |
Axial concentric coolant exit on circle |
EFW feed direction |
9.331 deg orthogonal rake |
13.934 deg helix flute |
63 mm L body |
98.3 mm L functional |
36 mm L clamping |
45.2 mm L usable |
3 maximum regrinds |
0.7 mm L point |
3 mm L regrind |
27500 r/min |
H6 connection diameter tolerance |
H7 achievable hole tolerance |
N material grade |
860.1..A1-NM (8xD) tool style |
