Sandvik Coromant 6228926 Adapter, 1-1/4 in Hole, Coromant® Capto® x Arbor Shank, C8 Taper, 1-1/4 in Nose, 1.1811 in Projection
Custom_Product_Images_Illustration
Sandvik Coromant 6228926 Adapter, 1-1/4 in Hole, Coromant® Capto® x Arbor Shank, C8 Taper, 1-1/4 in Nose, 1.1811 in Projection
SKU1229599
MFGR #6228926
Your Cost: $688.75/ea
Sandvik Coromant Adapter, 1-1/4 in Hole Dia, Coromant® Capto® x Arbor Shank, C8 Taper, 1-1/4 in Nose Dia, 1.1811 in Projection, 3.0708 in Overall Length, 3.1496 in Overall Dia, 3.1496 x 1-0.25 in Shank Connection, ANSI Code: C8-A391.05C-31 030M, ISO Code: C8-A391.05C-31 030M
Sandvik Coromant Adapter, 1-1/4 in Hole Dia, Coromant® Capto® x Arbor Shank, C8 Taper, 1-1/4 in Nose Dia, 1.1811 in Projection, 3.0708 in Overall Length, 3.1496 in Overall Dia, 3.1496 x 1-0.25 in Shank Connection, ANSI Code: C8-A391.05C-31 030M, ISO Code: C8-A391.05C-31 030M
Alternate Catalog Number C8-A391.05C-31 030M ANSI Code C8-A391.05C-31 030M Catalog Number 6228926 Country of Origin SE Gross Weight Per Pack 3.9600 lb ISO Code C8-A391.05C-31 030M Item Group 530 Overall Diameter 3.1496 in Overall Length 3.0708 in Series 31.75 mm Shank Connection Size 3.1496 x 1-0.25 in System Size Machine Side 5758305 Key, 5758321 Key, 5758458 Screw, 5763014 Mounting Screw and 6172837 Driving Key Type 5758305 Key, 5758321 Key, 5758458 Screw, 5763014 Mounting Screw and 6172837 Driving Key UPC 11 69826267944 Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer Sandvik Coromant Hole Diameter 1-1/4 in Nose Diameter 1-1/4 in Projection 1.1811 in Shank Type Coromant® Capto® x Arbor Taper Size C8 Steel body Axial concentric and radial coolant entry 80 bar coolant Axial concentric coolant exit on circle 80 mm Dia machine side connection 30 mm overhang 120 Nm torque Cx-A391.05C (1B) tool style 20 life cycle state
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | C8-A391.05C-31 030M |
| ANSI Code | C8-A391.05C-31 030M |
| Catalog Number | 6228926 |
| Country of Origin | SE |
| Gross Weight Per Pack | 3.9600 lb |
| ISO Code | C8-A391.05C-31 030M |
| Item Group | 530 |
| Overall Diameter | 3.1496 in |
| Overall Length | 3.0708 in |
| Series | 31.75 mm |
| Shank Connection Size | 3.1496 x 1-0.25 in |
| System Size Machine Side | 5758305 Key, 5758321 Key, 5758458 Screw, 5763014 Mounting Screw and 6172837 Driving Key |
| Type | 5758305 Key, 5758321 Key, 5758458 Screw, 5763014 Mounting Screw and 6172837 Driving Key |
| UPC 11 | 69826267944 |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | Sandvik Coromant |
| Hole Diameter | 1-1/4 in |
| Nose Diameter | 1-1/4 in |
| Projection | 1.1811 in |
| Shank Type | Coromant® Capto® x Arbor |
| Taper Size | C8 |
| Steel body |
| Axial concentric and radial coolant entry |
| 80 bar coolant |
| Axial concentric coolant exit on circle |
| 80 mm Dia machine side connection |
| 30 mm overhang |
| 120 Nm torque |
| Cx-A391.05C (1B) tool style |
| 20 life cycle state |
