Sandvik Coromant 6188518 T-Max P Shank Tool, PCLNR/L..HP Tool Holder, CNMG 120408 (MIIDM) and CNMG 432 (MIIDN) Insert, -5 deg Lead, Rectangle Shank, Right Hand
Custom_Product_Images_Illustration
Sandvik Coromant 6188518 T-Max P Shank Tool, PCLNR/L..HP Tool Holder, CNMG 120408 (MIIDM) and CNMG 432 (MIIDN) Insert, -5 deg Lead, Rectangle Shank, Right Hand
SKU1247140
MFGR #6188518
Your Cost: $286.39/ea
Sandvik Coromant Shank Tool, Series: T-Max P, PCLNR/L..HP Tool Holder, 4-1/2 in Overall Length, Rectangle Shank, 3/4 in H x 3/4 in W Shank, Insert Compatibility: CNMG 120408 (MIIDM) and CNMG 432 (MIIDN), 1/2 Insert Seat, Right Hand Cutting, -5 deg Lead Angle, ANSI Code: PCLNR 12 4BHP, ISO Code: PCLNR 12 4BHP, -6 deg Rake, Steel
Sandvik Coromant Shank Tool, Series: T-Max P, PCLNR/L..HP Tool Holder, 4-1/2 in Overall Length, Rectangle Shank, 3/4 in H x 3/4 in W Shank, Insert Compatibility: CNMG 120408 (MIIDM) and CNMG 432 (MIIDN), 1/2 Insert Seat, Right Hand Cutting, -5 deg Lead Angle, ANSI Code: PCLNR 12 4BHP, ISO Code: PCLNR 12 4BHP, -6 deg Rake, Steel
ANSI Code PCLNR 12 4BHP Catalog Number 6188518 Country of Origin SE Gross Weight Per Pack 0.8200 lb Insert Seat Size 1/2 ISO Code PCLNR 12 4BHP Material Steel Series T-Max P Shank Type Rectangle UPC 11 69826268127 Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer SANDVIK COROMANT CO Cutting Direction Right Hand Insert Compatibility CNMG 120408 (MIIDM) and CNMG 432 (MIIDN) Lead Angle -5 deg Overall Length 4-1/2 in Rake -6 deg Shank Size 3/4 in H x 3/4 in W Tool Holder Style PCLNR/L..HP 0 deg body machine side 0 deg body workpiece side Axial concentric coolant entry Decentral focused coolant exit with nozzles -6 deg inclination 95 deg cutting edge 0 deg maximum ramping 20 life cycle state 31.3 mm maximum overhang 5 Nm torque 25 mm W functional Lever hole clamping C - 80 deg diamond insert ANSI Code: PCLNR 12 4BHP ISO Code: PCLNR 12 4BHP
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| ANSI Code | PCLNR 12 4BHP |
| Catalog Number | 6188518 |
| Country of Origin | SE |
| Gross Weight Per Pack | 0.8200 lb |
| Insert Seat Size | 1/2 |
| ISO Code | PCLNR 12 4BHP |
| Material | Steel |
| Series | T-Max P |
| Shank Type | Rectangle |
| UPC 11 | 69826268127 |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | SANDVIK COROMANT CO |
| Cutting Direction | Right Hand |
| Insert Compatibility | CNMG 120408 (MIIDM) and CNMG 432 (MIIDN) |
| Lead Angle | -5 deg |
| Overall Length | 4-1/2 in |
| Rake | -6 deg |
| Shank Size | 3/4 in H x 3/4 in W |
| Tool Holder Style | PCLNR/L..HP |
| 0 deg body machine side |
| 0 deg body workpiece side |
| Axial concentric coolant entry |
| Decentral focused coolant exit with nozzles |
| -6 deg inclination |
| 95 deg cutting edge |
| 0 deg maximum ramping |
| 20 life cycle state |
| 31.3 mm maximum overhang |
| 5 Nm torque |
| 25 mm W functional |
| Lever hole clamping |
| C - 80 deg diamond insert |
| ANSI Code: PCLNR 12 4BHP |
| ISO Code: PCLNR 12 4BHP |
