Sandvik Coromant 6144149 CoroCut® 1-2, N123G2-0300-0003-TF Insert, 1.1811 in, Steel
Custom_Product_Images_Illustration
Sandvik Coromant 6144149 CoroCut® 1-2, N123G2-0300-0003-TF Insert, 1.1811 in, Steel
SKU1247392
MFGR #6144149
Your Cost: $291.66/ea
Sandvik Coromant Parting Off and Grooving Blade, Series: CoroCut® 1-2, 1.0196 in Blade Height, 1.1811 in Maximum Depth of Cut, 4.3307 in Overall Length, Left Hand Cutting, Insert Compatibility: N123G2-0300-0003-TF, G Insert Seat, Steel
Sandvik Coromant Parting Off and Grooving Blade, Series: CoroCut® 1-2, 1.0196 in Blade Height, 1.1811 in Maximum Depth of Cut, 4.3307 in Overall Length, Left Hand Cutting, Insert Compatibility: N123G2-0300-0003-TF, G Insert Seat, Steel
Alternate Catalog Number LF123G30-21B1 Blade Style R/LF123..B1 (C) Catalog Number 6144149 Country of Origin SE Gross Weight Per Pack 0.3600 lb Insert Seat Size G Item Group 420 Maximum Depth of Cut 1.181 in Series CoroCut® 1-2 Single or Double End Single End UPC 11 69826268066 Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer Sandvik Coromant Blade Height 1.02 in Blade Thickness 0.105 in Cutting Direction Left Hand Insert Compatibility N123G2-0300-0003-TF Material Steel Overall Length 4.331 in 0 deg body workpiece side 20 life cycle state Without coolant entry 60 mm Dia maximum workpiece parting No coolant exit 21 mm connection 0 deg rake orthogonal 21.4 mm H functional 90 deg cutting edge 0 deg inclination 110 mm length to cutting item reference point 51 mm overhang R/LF123..B1 (C) style 6.85 mm W functiona ANSI Code: LF123G30-21B1 ISO Code: LF123G30-21B1
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | LF123G30-21B1 |
| Blade Style | R/LF123..B1 (C) |
| Catalog Number | 6144149 |
| Country of Origin | SE |
| Gross Weight Per Pack | 0.3600 lb |
| Insert Seat Size | G |
| Item Group | 420 |
| Maximum Depth of Cut | 1.181 in |
| Series | CoroCut® 1-2 |
| Single or Double End | Single End |
| UPC 11 | 69826268066 |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | Sandvik Coromant |
| Blade Height | 1.02 in |
| Blade Thickness | 0.105 in |
| Cutting Direction | Left Hand |
| Insert Compatibility | N123G2-0300-0003-TF |
| Material | Steel |
| Overall Length | 4.331 in |
| 0 deg body workpiece side |
| 20 life cycle state |
| Without coolant entry |
| 60 mm Dia maximum workpiece parting |
| No coolant exit |
| 21 mm connection |
| 0 deg rake orthogonal |
| 21.4 mm H functional |
| 90 deg cutting edge |
| 0 deg inclination |
| 110 mm length to cutting item reference point |
| 51 mm overhang |
| R/LF123..B1 (C) style |
| 6.85 mm W functiona |
| ANSI Code: LF123G30-21B1 |
| ISO Code: LF123G30-21B1 |
