- Features
18 mm D maximum cutting |
20 life cycle state |
90 deg body workpiece side |
Axial concentric coolant entry |
10 bar coolant |
72 - 100 mm OD minimum axial groove |
Radial coolant exit |
64 mm Dia minimum inside axial groove |
90 deg cutting edge |
0 deg rake orthogonal |
18 mm L functional |
45.1 mm W functional |
0.1 mm H functional |
16 mm length to cutting item reference point |
H insert seat size |
3 Nm torque |
0 deg inclination |
18 mm maximum overhang |
570-xxR/L123..B..A tool style |
D-55 deg diamond insert shape |
