- Features
18 mm D maximum cutting |
20 life cycle state |
90 deg body workpiece side |
Axial concentric coolant entry |
10 bar coolant |
185 - 500 mm OD minimum axial groove |
Radial coolant exit |
175 mm Dia minimum inside axial groove |
90 deg cutting edge |
0 deg rake orthogonal |
18 mm L functional |
45.1 mm W functional |
0.1 mm H functional |
15.5 mm length to cutting item reference point |
3/16 in THK insert |
J insert seat size |
3.5 Nm torque |
0 deg inclination |
18 mm maximum overhang |
570-xxR/L123..B..A tool style |
