- Features
| 18 mm D maximum cutting |
| 20 life cycle state |
| 90 deg body workpiece side |
| Axial concentric coolant entry |
| 10 bar coolant |
| 228 - 500 mm OD minimum axial groove |
| Radial coolant exit |
| 220 mm Dia minimum inside axial groove |
| 90 deg cutting edge |
| 0 deg rake orthogonal |
| 18 mm L functional |
| 45.1 mm W functional |
| 0.1 mm H functional |
| 16 mm length to cutting item reference point |
| 19 mm L protruding |
| H insert seat size |
| 3 Nm torque |
| 0 deg inclination |
| 18 mm maximum overhang |
| 570-xxR/L123..B..B tool style |
