Sandvik Coromant 6010085 CoroMill® 327 Thread Milling Head, 327R09-18 10UN-TH 1025, 327..UN-TH Insert, Carbide, 1025, 327R09-18 10UN-TH 1025
Custom_Product_Images_Illustration
Sandvik Coromant 6010085 CoroMill® 327 Thread Milling Head, 327R09-18 10UN-TH 1025, 327..UN-TH Insert, Carbide, 1025, 327R09-18 10UN-TH 1025
SKU1231303
MFGR #6010085
Your Cost: $100.71/ea
List: Sandvik Coromant Thread Milling Head, Series: CoroMill® 327, 327..UN-TH Insert, 1/2 in Length, Manufacturer's Grade: 1025, ANSI Code: 327R09-18 10UN-TH 1025, ISO Code: 327R09-18 10UN-TH 1025, Right Hand, Carbide, PVD Coated, Material Grade: K/M/N/P/S
Sandvik Coromant Thread Milling Head, Series: CoroMill® 327, 327..UN-TH Insert, 1/2 in Length, Manufacturer's Grade: 1025, ANSI Code: 327R09-18 10UN-TH 1025, ISO Code: 327R09-18 10UN-TH 1025, Right Hand, Carbide, PVD Coated, Material Grade: K/M/N/P/S
Alternate Catalog Number 327R09-18 10UN-TH 1025 ANSI Code 327R09-18 10UN-TH 1025 Catalog Number 6010085 Corner Radius PVD Country of Origin TH Finish PVD Coated Gross Weight Per Pack 0.0100 lb Hand of Insert Right Hole Diameter 5.85 mm Included Angle 60 ISO Code 327R09-18 10UN-TH 1025 Item Group 350 Lead Angle 3 Length 1/2 in Series CoroMill® 327 Thickness 327R09-18 10UN-TH 1025 Thread Standard UN Thread Type Internal Threads Per Inch 10 Type Right UPC 11 69826254720 Width 327..UN-TH Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer Sandvik Coromant Chipbreaker Carbide Cutting Direction Right Hand Inscribed Circle CoroMill® 327 Insert Size K, M, N, P, S Insert Style 327..UN-TH Manufacturer's Grade 1025 Material Carbide Material Grade K/M/N/P/S Rake 327..UN-TH Shape 5.85 mm 14.96 mm Dia neck CoroMill® 327 adaptive interface 1.37 mm maximum cutting depth 14.96 mm Dia body 0 deg body half taper 10.62 mm Dia core at face Without coolant entry 17.7 mm Dia cutting Standard flute EFW feed direction 0 deg neutral helix flute 90 deg cutting edge 4.65 mm L body 4.65 mm L functional 5.85 mm L usable 5.85 mm maximum overhang UN60 thread form 10 TPI INT thread 3 effective cutting edge
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| Alternate Catalog Number | 327R09-18 10UN-TH 1025 |
| ANSI Code | 327R09-18 10UN-TH 1025 |
| Catalog Number | 6010085 |
| Corner Radius | PVD |
| Country of Origin | TH |
| Finish | PVD Coated |
| Gross Weight Per Pack | 0.0100 lb |
| Hand of Insert | Right |
| Hole Diameter | 5.85 mm |
| Included Angle | 60 |
| ISO Code | 327R09-18 10UN-TH 1025 |
| Item Group | 350 |
| Lead Angle | 3 |
| Length | 1/2 in |
| Series | CoroMill® 327 |
| Thickness | 327R09-18 10UN-TH 1025 |
| Thread Standard | UN |
| Thread Type | Internal |
| Threads Per Inch | 10 |
| Type | Right |
| UPC 11 | 69826254720 |
| Width | 327..UN-TH |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | Sandvik Coromant |
| Chipbreaker | Carbide |
| Cutting Direction | Right Hand |
| Inscribed Circle | CoroMill® 327 |
| Insert Size | K, M, N, P, S |
| Insert Style | 327..UN-TH |
| Manufacturer's Grade | 1025 |
| Material | Carbide |
| Material Grade | K/M/N/P/S |
| Rake | 327..UN-TH |
| Shape | 5.85 mm |
| 14.96 mm Dia neck |
| CoroMill® 327 adaptive interface |
| 1.37 mm maximum cutting depth |
| 14.96 mm Dia body |
| 0 deg body half taper |
| 10.62 mm Dia core at face |
| Without coolant entry |
| 17.7 mm Dia cutting |
| Standard flute |
| EFW feed direction |
| 0 deg neutral helix flute |
| 90 deg cutting edge |
| 4.65 mm L body |
| 4.65 mm L functional |
| 5.85 mm L usable |
| 5.85 mm maximum overhang |
| UN60 thread form |
| 10 TPI |
| INT thread |
| 3 effective cutting edge |
