- Features
0 deg body machine side |
Steel body |
Without coolant entry |
40 - 60 deg insert screw clamping interface |
No coolant exit |
148 mm Dia minimum bore |
0 deg orthogonal rake |
84 deg tool cutting edge |
0 deg inclination |
40 mm L functional |
41.2 mm L protruding |
SCMT 12 04 08 (MIIDM), BORCRT_IND (MIIDN) interface |
30.16 mm H |
43.2 mm OAL |
44.54 mm W |
40 mm overhang |
S - Square insert |
3.9 Nm torque |
42 mm W functional |
Peripheral effective cutt edge count |
