Sandvik Coromant 5751060 ModulMill Milling Insert, SMKR 42E2 L-WH 4030, S-Square, SPKR-WH Insert, Carbide, 4030, SPKR 12 03 ED L-WH 4030
SMKR [SPKR] Milling Inserts
1239804
MFG #: 5751060
Sandvik Coromant
15.95000
/ ea
Sandvik Coromant Milling Insert, Series: ModulMill, SPKR-WH Insert, S-Square, 1/2 in Inscribed Circle, 1/8 in Thickness, 0.5275 in Length, WH Chipbreaker, 8 deg Rake, Manufacturer's Grade: 4030, ANSI Code: SMKR 42E2 L-WH 4030, ISO Code: SPKR 12 03 ED L-WH 4030, Left Hand, Carbide, MTCVD Coated, Material Grade: K/P
- Features
| Flat surface clamping interface |
| 90 deg included angle |
| 75 deg cutting edge angle |
| 40 life cycle state |
| 1.4 mm wiper edge |
| 1-side cutting |
| 0.1 to 0.31 mm/r cutting feed |
