Sandvik Coromant 5739853 CoroMill® 210 Face Milling Cutter, 1.5551 in Cutting, 3/4 in Shank, 1.969 in OAL, RA210..Rxx Insert, 0.0787 in Max Depth of Cut
Custom_Product_Images_Illustration
Sandvik Coromant 5739853 CoroMill® 210 Face Milling Cutter, 1.5551 in Cutting, 3/4 in Shank, 1.969 in OAL, RA210..Rxx Insert, 0.0787 in Max Depth of Cut
SKU418156
MFGR #5739853
Your Cost: $962.52/ea
Sandvik Coromant Face Milling Cutter, Series: CoroMill® 210, 1.5551 in Cutting Dia, 1.969 in Overall Length, 0.0787 in Maximum Depth of Cut, RA210..Rxx Insert, 5 Inserts, Insert Compatibility: R210-140512M/E-, 3/4 in Shank Dia, Right Hand Cutting, 10 deg Cutting Angle, ANSI Code: RA210-063R19-14H, ISO Code: RA210-063R19-14H, Steel
Sandvik Coromant Face Milling Cutter, Series: CoroMill® 210, 1.5551 in Cutting Dia, 1.969 in Overall Length, 0.0787 in Maximum Depth of Cut, RA210..Rxx Insert, 5 Inserts, Insert Compatibility: R210-140512M/E-, 3/4 in Shank Dia, Right Hand Cutting, 10 deg Cutting Angle, ANSI Code: RA210-063R19-14H, ISO Code: RA210-063R19-14H, Steel
Alternate Catalog Number RA210-063R19-14H ANSI Code RA210-063R19-14H Arbor Hole Diameter 3/4 in Brand Sandvik Coromant Catalog Number 5739853 Country of Origin US Cutting Angle 10 ° Cutting Diameter 1.5551 in Cutting Direction Right Hand Gross Weight Per Pack 2.1400 lb Insert Compatibility R210-140512M/E- Insert Style RA210..Rxx ISO Code RA210-063R19-14H Item Group 450 Lead Angle 10 ° Manufacturer Sandvik Coromant Material Steel Maximum Depth of Cut 0.0787 in Number of Inserts 5 Overall Length 1.969 in Series CoroMill® 210 Shank Diameter 3/4 in Shank Type Arbor Standards ISO 6462:2011 Stock Status NONSTOCK Through Coolant Yes UPC 11 69826227972 UPC 12 69826227972 Axial concentric coolant entry Hexagon socket head cap screw adaptive interface Axial concentric coolant entry 10 bar coolant pressure 40 - 60 deg insert screw clamping interface 63.5 mm Dia maximum cutting 8.15 mm W keyway 50.0126 mm overhang 3.8 deg maximum ramping 18200 r/min 5 Nm torque 20 life cycle state Hexagon socket head cap screw adaptive interface
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| Alternate Catalog Number | RA210-063R19-14H |
| ANSI Code | RA210-063R19-14H |
| Arbor Hole Diameter | 3/4 in |
| Brand | Sandvik Coromant |
| Catalog Number | 5739853 |
| Country of Origin | US |
| Cutting Angle | 10 ° |
| Cutting Diameter | 1.5551 in |
| Cutting Direction | Right Hand |
| Gross Weight Per Pack | 2.1400 lb |
| Insert Compatibility | R210-140512M/E- |
| Insert Style | RA210..Rxx |
| ISO Code | RA210-063R19-14H |
| Item Group | 450 |
| Lead Angle | 10 ° |
| Manufacturer | Sandvik Coromant |
| Material | Steel |
| Maximum Depth of Cut | 0.0787 in |
| Number of Inserts | 5 |
| Overall Length | 1.969 in |
| Series | CoroMill® 210 |
| Shank Diameter | 3/4 in |
| Shank Type | Arbor |
| Standards | ISO 6462:2011 |
| Stock Status | NONSTOCK |
| Through Coolant | Yes |
| UPC 11 | 69826227972 |
| UPC 12 | 69826227972 |
| Axial concentric coolant entry |
| Hexagon socket head cap screw adaptive interface |
| Axial concentric coolant entry |
| 10 bar coolant pressure |
| 40 - 60 deg insert screw clamping interface |
| 63.5 mm Dia maximum cutting |
| 8.15 mm W keyway |
| 50.0126 mm overhang |
| 3.8 deg maximum ramping |
| 18200 r/min |
| 5 Nm torque |
| 20 life cycle state |
| Hexagon socket head cap screw adaptive interface |
