SQD ABR1S411F INTERFACE RELAY - ELE
SKU466785
MFGR #ABR1S411F
Your Cost: $87.70/ea
Telemecanique,INTERFACE RELAY - ELECTROMECHANICAL,-5...40 deg.C unrestricted operation/-20...60 deg.C at Un,1 NO,12 A conforming to IEC 60947-1,125 V DC,17.5mm,17V,50/60Hz,<=34V,>= 20000000 cycles,Schneider Electric Screw clamp terminal,UL, IEC,asymmetrical DIN railcombination railsymmetrical DIN rail,electromechanical output interface module electromechanical output interface module,interface for discrete signals
Telemecanique,INTERFACE RELAY - ELECTROMECHANICAL,-5...40 deg.C unrestricted operation/-20...60 deg.C at Un,1 NO,12 A conforming to IEC 60947-1,125 V DC,17.5mm,17V,50/60Hz,<=34V,>= 20000000 cycles,Schneider Electric Screw clamp terminal,UL, IEC,asymmetrical DIN railcombination railsymmetrical DIN rail,electromechanical output interface module electromechanical output interface module,interface for discrete signals
Amperage Rating 12 A CONFORMING TO IEC 60947-1 Application INTERFACE FOR DISCRETE SIGNALS ARRA Compliant C Brand Schneider Electric Buy American Compliant C Catalog Number ABR1S411F Coil 125 V DC Connection Screw Clamp Terminal Contact Configuration 1 NO Contact Rating 8 MA AC Country of Origin FR Drop Down Voltage <=34V EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 9.14 Gross Volume per Pack Metric 149.70 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.2400 lb Gross Weight per Pack Metric 0.11 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536490075 Height 3.50 in Height [Metric] 8.8900 cm Item Group 22375 Length 0.90 in Length [Metric] 22.8600 mm Manufacturer Schneider Electric Mounting ASYMMETRICAL DIN RAILCOMBINATION RAILSYMMETRICAL DIN RAIL Operating Temperature -5...40 °C UNRESTRICTED OPERATION/-20...60 °C AT UN Pickup Voltage 17V Returnable N Size 17.5MM Standard UL, IEC Stock Status NONSTOCK Sub Brand SCHNEIDER ELECTRIC Type ELECTROMECHANICAL OUTPUT INTERFACE MODULE ELECTROMECHANICAL OUTPUT INTERFACE MODULE UNSPSC 39122325 UPC 11 78590192358 UPC 12 785901923589 Width 2.90 in Width [Metric] 7.3660 cm INTERFACE FOR DISCRETE SIGNALS GREEN MECHANICAL INDICATOR FOR POSITION OF CONTACTS 1 GREEN LED CONTROL SIGNAL STATE
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Amperage Rating | 12 A CONFORMING TO IEC 60947-1 |
| Application | INTERFACE FOR DISCRETE SIGNALS |
| ARRA Compliant | C |
| Brand | Schneider Electric |
| Buy American Compliant | C |
| Catalog Number | ABR1S411F |
| Coil | 125 V DC |
| Connection | Screw Clamp Terminal |
| Contact Configuration | 1 NO |
| Contact Rating | 8 MA AC |
| Country of Origin | FR |
| Drop Down Voltage | <=34V |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 9.14 |
| Gross Volume per Pack Metric | 149.70 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.2400 lb |
| Gross Weight per Pack Metric | 0.11 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536490075 |
| Height | 3.50 in |
| Height [Metric] | 8.8900 cm |
| Item Group | 22375 |
| Length | 0.90 in |
| Length [Metric] | 22.8600 mm |
| Manufacturer | Schneider Electric |
| Mounting | ASYMMETRICAL DIN RAILCOMBINATION RAILSYMMETRICAL DIN RAIL |
| Operating Temperature | -5...40 °C UNRESTRICTED OPERATION/-20...60 °C AT UN |
| Pickup Voltage | 17V |
| Returnable | N |
| Size | 17.5MM |
| Standard | UL, IEC |
| Stock Status | NONSTOCK |
| Sub Brand | SCHNEIDER ELECTRIC |
| Type | ELECTROMECHANICAL OUTPUT INTERFACE MODULE ELECTROMECHANICAL OUTPUT INTERFACE MODULE |
| UNSPSC | 39122325 |
| UPC 11 | 78590192358 |
| UPC 12 | 785901923589 |
| Width | 2.90 in |
| Width [Metric] | 7.3660 cm |
| INTERFACE FOR DISCRETE SIGNALS |
| GREEN MECHANICAL INDICATOR FOR POSITION OF CONTACTS 1 GREEN LED CONTROL SIGNAL STATE |
