SIRIUS 3RT2026-1FB40 Power Contactor 3RT2026-1FB40, 24 VDC Coil, 25 A Max Load, 3NO, 3 Poles
Custom_Product_Images_Illustration
SIRIUS 3RT2026-1FB40 Power Contactor 3RT2026-1FB40, 24 VDC Coil, 25 A Max Load, 3NO, 3 Poles
SKU715901
MFGR #3RT20261FB40
Your Cost: $262.80/ea
List: SIEMENS 3RT20261FB40 CONTACTOR S0 25A 24VDC 1NO/1NC SCREW
SIEMENS 3RT20261FB40 CONTACTOR S0 25A 24VDC 1NO/1NC SCREW
Alternate Catalog Number 3RT2026-1FB40 Application Contactors for switching motors ARRA Compliant C Brand Siemens Buy American Compliant C Catalog Number 3RT20261FB40 Coil Power Rating 5.9 W Coil Voltage 24 VDC Connection screw-type terminals Connection Type Screw Contact Configuration 1NO-1NC Contact Rating A600/Q600 Country of Origin DE Currency USD Dimensions 85 mm H x 45 mm W x 107 mm D Enclosure Type IP20 EU RoHS Indicator C Gross Volume Per Pack 34.40 Gross Volume UOM in Gross Weight Per Pack 1.3300 lb Gross Weight per Pack Metric 0.61 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536490065 Height 3.6000 in Height [Metric] 9.1440 cm Length 4.5500 in Length [Metric] 11.5570 cm Manufacturer Siemens Maximum Load Current 25 A Mounting screw and snap-on mounting onto 35 mm standard mounting rail according to DIN EN 50022 +/-180? rotation possible on vertical mounting surface; can be tilted forward and backward by +/- 22.5? on vertical mounting surface Mounting Type DIN Rail/Snap-On/Threaded Number of Auxiliary Contacts 2 Number Of Poles 3 Operating Cycles 10000000 Operating Temperature -25 to 60 Phase 3 Returnable Y Size S0 Standards RoHS CompliantCCC CertifiedCSA CertifiedUL ListedEAC ApprovedC-TickCE CertifiedABS ApprovedBureau Veritas CertifiedLRS ListedPRS CertifiedRINA CertifiedRMRS ApprovedDNV-GL ApprovedVDE Approved Stock Status NONSTOCK Sub Brand Sirius Terminal Type Screw Type Standard UNSPSC 39121529 UPC 11 66264391387 UPC 12 662643913873 Wattage 11 kW Width 2.1000 in Width [Metric] 5.3340 cm Contactors for switching motors Contactors in size S00, S0?and S2 can be used to configure?star-delta (wye-delta) starters simply by plugging in function modules. These can also be equipped with an AS-i or IO-Link interface as an option, which significantly reduces the control circuit wiring. 5.9 W (closing/holding) magnet coil at DC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 3RT2026-1FB40 |
| Application | Contactors for switching motors |
| ARRA Compliant | C |
| Brand | Siemens |
| Buy American Compliant | C |
| Catalog Number | 3RT20261FB40 |
| Coil Power Rating | 5.9 W |
| Coil Voltage | 24 VDC |
| Connection | screw-type terminals |
| Connection Type | Screw |
| Contact Configuration | 1NO-1NC |
| Contact Rating | A600/Q600 |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 85 mm H x 45 mm W x 107 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 34.40 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 1.3300 lb |
| Gross Weight per Pack Metric | 0.61 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 3.6000 in |
| Height [Metric] | 9.1440 cm |
| Length | 4.5500 in |
| Length [Metric] | 11.5570 cm |
| Manufacturer | Siemens |
| Maximum Load Current | 25 A |
| Mounting | screw and snap-on mounting onto 35 mm standard mounting rail according to DIN EN 50022 +/-180? rotation possible on vertical mounting surface; can be tilted forward and backward by +/- 22.5? on vertical mounting surface |
| Mounting Type | DIN Rail/Snap-On/Threaded |
| Number of Auxiliary Contacts | 2 |
| Number Of Poles | 3 |
| Operating Cycles | 10000000 |
| Operating Temperature | -25 to 60 |
| Phase | 3 |
| Returnable | Y |
| Size | S0 |
| Standards | RoHS CompliantCCC CertifiedCSA CertifiedUL ListedEAC ApprovedC-TickCE CertifiedABS ApprovedBureau Veritas CertifiedLRS ListedPRS CertifiedRINA CertifiedRMRS ApprovedDNV-GL ApprovedVDE Approved |
| Stock Status | NONSTOCK |
| Sub Brand | Sirius |
| Terminal Type | Screw |
| Type | Standard |
| UNSPSC | 39121529 |
| UPC 11 | 66264391387 |
| UPC 12 | 662643913873 |
| Wattage | 11 kW |
| Width | 2.1000 in |
| Width [Metric] | 5.3340 cm |
| Contactors for switching motors |
| Contactors in size S00, S0?and S2 can be used to configure?star-delta (wye-delta) starters simply by plugging in function modules. These can also be equipped with an AS-i or IO-Link interface as an option, which significantly reduces the control circuit wiring. |
| 5.9 W (closing/holding) magnet coil at DC |
